EL1xxx | Digital input Parts





EtherCAT Terminal, 8-channel digital input, 24 V DC, 1 µs, ground switching, multi-timestamp


EtherCAT Terminal, 4-channel digital input, 24 V DC, 3 ms, isolation voltage 2500 V DC

EtherCAT Terminal, 2-channel digital input + 2-channel digital output, 5 V DC, 100 ns, 0.1 A, RS422/RS485, oversampling







Compare EL1xxx | Digital input
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Connection technology | Current consumption power contacts | Current consumption E-bus | Weight | “0” signal voltage |
|---|---|---|---|---|---|
| EL1918 | 1-/2-wire | see documentation | typ. 165 mA | approx. 50 g | — |
| ELX1054 | — | typ. 15 mA + load | typ. 70 mA | approx. 55 g | — |
| EL1254 | 4-wire | typ. 20 mA + load | typ. 80 mA | approx. 55 g | -3…+5 V (similar to EN 61131-2, type 3) |
| ELX1058 | — | typ. 15 mA + load | typ. 70 mA | approx. 55 g | — |
| EL1258-0010 | 2-wire | typ. 6 mA | typ. 130 mA | approx. 55 g | 18…30 V |
| EL1899 | 1-wire | typ. 35 mA | typ. 110 mA | approx. 55 g | 18…30 V |
| EL1004-0020 | 2-wire | typ. 2 mA + load | typ. 90 mA | approx. 50 g | -3…+5 V (EN 61131-2, type 3) |
| EL1262-0010 | D-sub, 9-pin | – | typ. 540 mA | approx. 55 g | — |
| EL1409 | 1-wire | typ. 4 mA + load | typ. 70 mA | approx. 65 g | 5 V |
| EL1252-0010 | 4-wire | typ. 6 mA + load | typ. 110 mA | approx. 55 g | -3…+5 V (similar to EN 61131-2, type 3) |
| EL1417 | 1-wire | typ. 5 mA | typ. 60 mA | approx. 100 g | 5 V DC |
| EL1489 | 1-wire | typ. 10 mA + load | typ. 65 mA | approx. 65 g | 19…24 V at 24 V DC nominal voltage |
| EL1429 | 1-wire | typ. 2 mA + load | typ. 110 mA | approx. 65 g | 9…15 V at 24 V DC nominal voltage |
| EL1264 | 4-wire | typ. 20 mA + load | typ. 70 mA | approx. 55 g | -3…+5 V (similar to EN 61131-2, type 3) |
| EL1252-0060 | 4-wire | – | typ. 110 mA | approx. 55 g | 3 V |
Common to all listed parts
| Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Side by side mounting by means of | double slot and key connection |
