Mitsubishi Low-voltage switchgear – Magnetic Contactors Parts
























Compare Mitsubishi Low-voltage switchgear – Magnetic Contactors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | Main Contact Making Current Capacity [A]: Category AC-3: AC220V | Operation Coil Properties: Normal input [VA] |
|---|---|---|---|---|---|
| S-T100DL | 100 | 105 | 105 | 1050 | 27 |
| S-T100 | 100 | 105 | 105 | 1050 | 23 |
| S-T80DL | 80 | 85 | 85 | 850 | 26 |
| S-T80CW | 80 | 85 | 85 | 850 | 20 |
| S-T80 | 80 | 85 | 85 | 850 | 20 |
| S-T65DL | 65 | 65 | 65 | 650 | 26 |
| S-T65CW | 65 | 65 | 65 | 650 | 20 |
| S-T65 | 65 | 65 | 65 | 650 | 20 |
| S-T50DL | 50 | 55 | 50 | 550 | 24 |
| S-T50BCSA | 50 | 55 | 50 | 550 | 10 |
| S-T50SA | 50 | 55 | 50 | 550 | 10 |
| S-T50BC | 50 | 55 | 50 | 550 | 10 |
| S-T50 | 50 | 55 | 50 | 550 | 10 |
| S-T35DL | 35 | 40 | 40 | 400 | 24 |
| S-T35BCSA | 35 | 40 | 40 | 400 | 10 |
| S-T35SA | 35 | 40 | 40 | 400 | 10 |
| S-T35BC | 35 | 40 | 40 | 400 | 10 |
| S-T35 | 35 | 40 | 40 | 400 | 10 |
| S-T32BCSA | 32 | 32 | 32 | 320 | 4.5 |
| S-T32SA | 32 | 32 | 32 | 320 | 4.5 |
| S-T32BC | 32 | 32 | 32 | 320 | 4.5 |
| S-T32 | 32 | 32 | 32 | 320 | 4.5 |
| S-T25BCSA | 26 | 30 | 30 | 300 | 7 |
| S-T25SA | 26 | 30 | 30 | 300 | 7 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Insulation Voltage Ui [V] | 690 |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Contact Arrangements (Valid): Main Contact (Standard) | 3NO |
| Electrical Durability [Mil.Times]: Category AC-1 | 50 |
| Electrical Durability [Mil.Times]: Category DC2,DC4 | 50 |
| Electrical Durability [Mil.Times]: Category DC1 | 50 |
| Operation Coil Properties: Operating Voltage | AC Operated |
