Mitsubishi Low-voltage switchgear – Magnetic Contactors Parts
























Compare Mitsubishi Low-voltage switchgear – Magnetic Contactors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V |
|---|---|---|---|---|---|
| SD-T35BCSA | 11 | 18.5 | 18.5 | 35 | 40 |
| SD-T35SA | 11 | 18.5 | 18.5 | 35 | 40 |
| SD-T35BC | 11 | 18.5 | 18.5 | 35 | 40 |
| SD-T35 | 11 | 18.5 | 18.5 | 35 | 40 |
| SD-T32BCSA | 7.5 | 15 | 15 | 32 | 32 |
| SD-T32SA | 7.5 | 15 | 15 | 32 | 32 |
| SD-T32BC | 7.5 | 15 | 15 | 32 | 32 |
| SD-T32 | 7.5 | 15 | 15 | 32 | 32 |
| SD-T21BCSA | 5.5 | 11 | 11 | 20 | 25 |
| SD-T21SA | 5.5 | 11 | 11 | 20 | 25 |
| SD-T21BC | 5.5 | 11 | 11 | 20 | 25 |
| SD-T21 | 5.5 | 11 | 11 | 20 | 25 |
| SD-T20SASQ | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T20SQ | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T20BCSA | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T20SA | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T20BC | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T20 | 4.5 | 7.5 | 7.5 | 18 | 18 |
| SD-T12SASQ | 3.5 | 5.5 | 5.5 | 13 | 13 |
| SD-T12SQ | 3.5 | 5.5 | 5.5 | 13 | 13 |
| SD-T12BCSA | 3.5 | 5.5 | 5.5 | 13 | 13 |
| SD-T12SA | 3.5 | 5.5 | 5.5 | 13 | 13 |
| SD-T12BC | 3.5 | 5.5 | 5.5 | 13 | 13 |
| SD-T12 | 3.5 | 5.5 | 5.5 | 13 | 13 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Product Specification | DC Operated |
| Rated Insulation Voltage Ui [V] | 690 |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Contact Arrangements (Valid): Main Contact (Standard) | 3NO |
| Mechanical Durability [Mil.Times] | 1000 |
| Electrical Durability [Mil.Times]: Category AC-1 | 50 |
| Electrical Durability [Mil.Times]: Category DC2,DC4 | 50 |
