S-T80 Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN: S-T80 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Magnetic Contactors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can S-T80 be shipped?

S-T80 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up S-T80 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for S-T80 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for S-T80, subject to availability and destination.

The Mitsubishi Electric S-T80 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 80A (Category AC-3 AC200V) AC Operated. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	Representative rating 80A (Category AC-3 AC200V) AC Operated

Specifications

Product Specification	AC Operated
Rated Insulation Voltage Ui [V]	690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	19
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	37
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V	22
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V	45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V	45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V	45
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V	41
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V	83
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V	85
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC690V	100
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V	12
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V	24
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	80
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	80
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	75
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V	85
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V	85
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V	75
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V	52
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V	120
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V	120
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V	100
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC690V	100
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V	120
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V	120
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC24V	65
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC48V	40
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V	20
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V	5
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC24V	80
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC48V	60
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC110V	50
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC220V	20
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC24V	80
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC48V	65
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC110V	50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC220V	20
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC24V	80
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC48V	80
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC110V	80
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC220V	60
Main Contact Conventional Free Air Thermal Current [A]	120
Main Contact Minimal Applicable Load	48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V	6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V	3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V	1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V	1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V	10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V	8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V	5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V	5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V	3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V	1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V	0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V	0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V	10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V	8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V	5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V	1
Auxiliary Contact Conventional Free Air Thermal Current [A]	10
Auxiliary Contact Minimal Applicable Load	20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)	3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)	2NO2NC
Main Contact Making Current Capacity [A]: Category AC-3: AC220V	850
Main Contact Making Current Capacity [A]: Category AC-3: AC440V	850
Main Contact Making Current Capacity [A]: Category AC-3: AC550V	750
Main Contact Making Current Capacity [A]: Category AC-3: AC690V	520
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V	680
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V	680
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V	600
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V	416
Mechanical Durability [Mil.Times]	500
Electrical Durability [Mil.Times]: Category AC-3 (Japan)	100
Electrical Durability [Mil.Times]: Category AC-1	50
Electrical Durability [Mil.Times]: Category DC2,DC4	50
Electrical Durability [Mil.Times]: Category DC1	50
Switching Frequency [Times/Hour]: Category AC-3	1200
Operation Coil Properties: Operating Voltage	AC Operated
Operation Coil Properties: Inrush Input [VA]	115
Operation Coil Properties: Normal input [VA]	20
Operation Coil Properties: Power Consumption [W]	2.2
Functions: Coil Surge Absorbing Function	Yes
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting,DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)	M6
Terminal Screw Size: Main Circuit (Load Side)	M6
Terminal Screw Size: Operating Circuit	M4
Terminal Screw Size: Operation Coil	M4
