Mitsubishi Low-voltage switchgear – Magnetic Contactors Parts
























Compare Mitsubishi Low-voltage switchgear – Magnetic Contactors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V |
|---|---|---|---|---|---|
| S-T25BC | 5.5 | 7.5 | 15 | 15 | 26 |
| S-T25 | 5.5 | 7.5 | 15 | 15 | 26 |
| S-T21DL | 4 | 5.5 | 11 | 11 | 20 |
| S-T21BCSA | 4 | 5.5 | 11 | 11 | 20 |
| S-T21SA | 4 | 5.5 | 11 | 11 | 20 |
| S-T21BC | 4 | 5.5 | 11 | 11 | 20 |
| S-T21 | 4 | 5.5 | 11 | 11 | 20 |
| S-T20SASQ | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T20SQ | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T20BCSA | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T20SA | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T20BC | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T20 | 3.7 | 4.5 | 7.5 | 7.5 | 18 |
| S-T12DL | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12SASQ | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12SQ | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12BCSA | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12SA | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12BC | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T12 | 2.7 | 3.5 | 5.5 | 5.5 | 13 |
| S-T10BCSA | 2.2 | 2.5 | 4 | 4 | 11 |
| S-T10SA | 2.2 | 2.5 | 4 | 4 | 11 |
| S-T10BC | 2.2 | 2.5 | 4 | 4 | 11 |
| S-T10 | 2.2 | 2.5 | 4 | 4 | 11 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Insulation Voltage Ui [V] | 690 |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V | 1.2 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V | 10 |
