800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Contact block configuration | Operator cap color | Operator cap type | Operator function | Operator type |
|---|---|---|---|---|---|
| 800HC-FRXJTQ24RA1 | 1-NCLB 1-NO standard contacts | Red | Jumbo mushroom head | 2-position | Push-pull unit |
| 800H-QRM10GA4 | 2 NC, standard contact block | Green | Mushroom head | Momentary contact | Push button |
| 800H-QRM10A | 1 NO, 1 NC, standard contact block | Amber | Mushroom head | Momentary contact | Push button |
| 800H-QRAH2GA1 | 1 NCLB, 1 NO, standard contact block | Green | Extended head with guard | Momentary contact | Push button |
| 800HC-FRXTP16XA1 | 1-NCLB 1-NO standard contacts | No lens cap | Mushroom head | 2-position | Push-pull unit |
| 800HC-FRXTP16RG1 | 2-NO 2-NC standard contacts | Red | Mushroom head | 2-position | Push-pull unit |
| 800HC-FRXTP16GA1 | 1-NCLB 1-NO standard contacts | Green | Mushroom head | 2-position | Push-pull unit |
| 800HC-HR2D5 | 1-NO mini contact | Black with white Insert | Standard knob | Maintained | Selector switch |
| 800HC-HR2D1R | 1-NO logic reed contact | Black with white Insert | Standard knob | Maintained | Selector switch |
| 800HC-FRXTQH2RAY | 1-NO 1-NC stackable sealed | Red | Mushroom head | 2-position | Push-pull unit |
| 800H-TFRXJTQH2RG1V | 2-NO 2-NC PenTUFF contacts | Red | Jumbo mushroom head | 2-position maintained | Emergency stop push button |
| 800HC-FRXMQ24WA7 | 1-NCLB 1-NC standard contacts | White | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXMQ10RA1 | 1-NCLB 1-NO standard contacts | Red | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXJTP16RA5 | 2-NCLB standard contact | Red | Jumbo mushroom head | 2-position | Push-pull unit |
| 800HC-FRXJT9A1 | 1-NCLB 1-NO standard contacts | Yellow | Jumbo mushroom head | 2-position | Push-pull unit |
| 800HC-FRXJT7D1 | 1-NO standard contact | Blue | Jumbo mushroom head | 2-position | Push-pull unit |
| 800HC-FRXJT6D1 | 1-NO standard contact | Red | Jumbo mushroom head | 2-position | Push-pull unit |
| 800HC-FRXNQ24GA7 | 1-NCLB 1-NC standard contacts | Green | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXN1A7 | 1-NCLB 1-NC standard contacts | Green | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXNP26GA | 1-NO 1-NC standard contacts | Green | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXT9D1 | 1-NO standard contact | Yellow | Mushroom head | 2-position | Push-pull unit |
| 800HC-FRXN1A1 | 1-NCLB 1-NO standard contacts | Green | Mushroom head | 3-position | Push-pull unit |
| 800HC-FRXJT3D4 | 1-NCLB standard contact | Orange | Jumbo mushroom head | 2-position | Push-pull unit |
| 800HC-FRXT9AV | 1-NO 1-NC PenTUFF contacts | Yellow | Mushroom head | 2-position | Push-pull unit |
Common to all listed parts
| Repair options available | No |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
| Contact block termination wire range | 14 - 18 AWG (x2) |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Operating temperature | -25 °C |
| Operator construction/material | Plastic |
