800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Illumination module input voltage | Operator cap color | Operator cap type | Operator function | Operator cam code |
|---|---|---|---|---|---|
| 800H-QRB10WD1R | 120V AC/DC | White | Extended head without guard | Momentary contact | — |
| 800HC-26HRR2KB6AX | 240V AC @ 50/60Hz | Red | Standard knob | Maintained | KB6 |
| 800HC-26HRG2KB6AX | 240V AC @ 50/60Hz | Green | Standard knob | Maintained | KB6 |
| 800HC-24JRB91KB7AX | 24V AC/DC | Blue | Standard knob | Spring return from left and right | KB7 |
| 800HC-24JRA17KC7AX | 24V AC/DC | Amber | Knob lever | Maintained | KC7 |
| 800HC-24HRW17KB6AX | 24V AC/DC | White | Knob lever | Maintained | KB6 |
| 800HC-26JRG20KB7CX | 240V AC @ 50/60Hz | Green | Knob lever | Spring return from left and right | KB7 |
| 800HC-24HRR2KB6AA | 24V AC/DC | Red | Standard knob | Maintained | KB6 |
| 800HC-16JRB91KB7AX | 120V AC @ 50/60Hz | Blue | Standard knob | Spring return from left and right | KB7 |
| 800HC-16HRR2KB6DX | 120V AC @ 50/60Hz | Red | Standard knob | Maintained | KB6 |
| 800HC-16JRA91KB7AX | 120V AC @ 50/60Hz | Amber | Standard knob | Spring return from left and right | KB7 |
| 800HC-16HRB2KB6DX | 120V AC @ 50/60Hz | Blue | Standard knob | Maintained | KB6 |
| 800HC-16HRA2KB6DX | 120V AC @ 50/60Hz | Amber | Standard knob | Maintained | KB6 |
| 800HC-16HRA2KB6AX | 120V AC @ 50/60Hz | Amber | Standard knob | Maintained | KB6 |
| 800HC-12JRA5KB7AX | 12V AC/DC | Amber | Standard knob | Spring return from right | KB7 |
| 800HC-12HRG2KB6AA | 12V AC/DC | Green | Standard knob | Maintained | KB6 |
| 800HC-12HRA2KB6AX | 12V AC/DC | Amber | Standard knob | Maintained | KB6 |
| 800HC-16JRG2KC1BX | 120V AC @ 50/60Hz | Green | Standard knob | Maintained | KC1 |
| 800HC-16JRG2KB7AA | 120V AC @ 50/60Hz | Green | Standard knob | Maintained | KB7 |
| 800HC-16JRB20KB7AX | 120V AC @ 50/60Hz | Blue | Knob lever | Spring return from left and right | KB7 |
| 800H-QRM10RD2 | 120V AC/DC | Red | Mushroom head | Momentary contact | — |
| 800HC-16JRA2KB7AX | 120V AC @ 50/60Hz | Amber | Standard knob | Maintained | KB7 |
| 800HC-FRXT9D4S | — | Yellow | Mushroom head | 2-position | — |
| 800H-QRM10RA2 | 120V AC/DC | Red | Mushroom head | Momentary contact | — |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | March 31, 2025 |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Operating temperature | -25 °C |
| Operator cap/button material | Plastic |
