800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Operator cap color | Operator function | Operator cam code | Position 1 contact block | Position 3 contact block |
|---|---|---|---|---|---|
| 800H-AR6D1V | Red | Momentary contact | — | — | — |
| 800H-16HRR2KB6AL | Red | Maintained | KB6 | 1-NO 1-NC standard contacts | 1 NC, mini contact block (800T-XD6) |
| 800H-16HRR2KB6AD | Red | Maintained | KB6 | 1-NO 1-NC standard contacts | 1-NO standard contact |
| 800H-16HRR18KL8AX | Red | Spring return from left | KL8 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRA4KB7AX | Amber | Spring return from left | KB7 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRA2KB7CX | Amber | Maintained | KB7 | 1-NCLB 1-NC standard contacts | No block this position |
| 800H-16JRA2KC1AX | Amber | Maintained | KC1 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRA20KB7CX | Amber | Spring return from left and right | KB7 | 1-NCLB 1-NC standard contacts | No block this position |
| 800H-16JRA19KB7BX | Amber | Spring return from right | KB7 | 1-NCLB 1-NO standard contacts | No block this position |
| 800H-16JRW20KB7AX | White | Spring return from left and right | KB7 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRW19KC7AX | White | Spring return from right | KC7 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRW17KB7AA | White | Maintained | KB7 | 1-NO 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800H-16JRR91KB7CX | Red | Spring return from left and right | KB7 | 1-NCLB 1-NC standard contacts | No block this position |
| 800H-16HRG5KL8DX | Green | Spring return from right | KL8 | 1-NO standard contact | No block this position |
| 800H-16HRG5KL8AX | Green | Spring return from right | KL8 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRW2KB7AX | White | Maintained | KB7 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16HRW5KL8AX | White | Spring return from right | KL8 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16HRW17KB6AX | White | Maintained | KB6 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16HRW17KB6 | White | Maintained | KB6 | — | — |
| 800H-16JRW91KB7AX | White | Spring return from left and right | KB7 | 1-NO 1-NC standard contacts | No block this position |
| 800H-16JRW2KC1AX | White | Maintained | KC1 | 1-NO 1-NC standard contacts | No block this position |
| 800H-2HW4R-41895 | — | — | — | — | — |
| 800H-2HW4R-41896 | — | — | — | — | — |
| 800H-2HRCH2KB6AX | Clear | Maintained | KB6 | 1-NO 1-NC standard contacts | No block this position |
Common to all listed parts
| Repair options available | No |
