White Washdown Parts
Compare White Washdown
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Catalog Number | Power Factor | Rated Efficiency | Product Net Weight | Dimension Diagram |
|---|---|---|---|---|---|
| EWDM3546 | EWDM3546 | 66 % | 85.50 % | 39 lb | 35LYE2680 |
| EWDM3708T | EWDM3708T | 71 % | 89.50 % | 185 lb | 37LYE572 |
| CEWDNM3558T | CEWDNM3558T | 81 % | 86.50 % | 54 lb | 35LYSS592 |
| EWDM3705T | EWDM3705T | 62 % | 86.50 % | 111 lb | 37LYE572 |
| VWDM3534 | VWDM3534 | 49 % | 75.50 % | 33 lb | 35LYS603 |
| WDL3504 | WDL3504 | 70 % | 66 % | 34 lb | 35LYJ271 |
| WDL3507 | WDL3507 | 69 % | 70 % | 37 lb | 35LYJ271 |
| EWDM3558T | EWDM3558T | 77 % | 86.50 % | 46 lb | 35LYSS585 |
| CWDM3539 | CWDM3539 | 60 % | 78.50 % | 37 lb | 35LYS588 |
| CEWDM23932T | CEWDM23932T | 68 % | 91 % | 289 lb | 39LYR098 |
| VEFWDM3546T | VEFWDM3546T | 69 % | 85.50 % | 36 lb | 35LYSS605 |
| CWDM3543 | CWDM3543 | 62 % | 80 % | 46 lb | 35LYS588 |
| EWDM3554T | EWDM3554T | 72 % | 86.50 % | 49 lb | 35LYSS584 |
| CWDM3538-5 | CWDM3538-5 | 62 % | 80 % | 26 lb | 35LYS588 |
| VEFWDM3546 | VEFWDM3546 | 69 % | 85.50 % | 38 lb | 35LYS596 |
| VWDM3542 | VWDM3542 | 74 % | 82.50 % | 33 lb | 35LYS603 |
| CWDM3542-5 | CWDM3542-5 | 73 % | 82.50 % | 35 lb | 35LYS588 |
| EWDM3709T | EWDM3709T | 88 % | 89.50 % | 129 lb | 37LYE572 |
| VWDL3507 | VWDL3507 | 69 % | 70 % | 36 lb | 35LYS583 |
| CWDM3541-H | CWDM3541-H | 80 % | 80 % | 34 lb | 35LY-000-259 |
| EWDM3610T | EWDM3610T | 92 % | 86.50 % | 50 lb | 35LY-000-240 |
| VEWDM3546 | VEWDM3546 | 66 % | 85.50 % | 40 lb | 35LYS603 |
| VEWDM3542 | VEWDM3542 | 74 % | 82.50 % | 32 lb | 35LYS603 |
| WDL3510 | WDL3510 | 76 % | 68 % | 41 lb | 35LYJ271 |
Common to all listed parts
| Brand / Label | Baldor-Reliance |
| Country or Territory of Origin | United States |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Ambient Temperature | 40 °C |
| Duty Time | 60 Min |
| Insulation Class | F |
| Number of Speeds | Single Speed |
