SIRIUS 3RV2 motor starter protectors Parts
Browse Subcategories
Compare SIRIUS 3RV2 motor starter protectors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | continuous current rated value | Net Weight | adjustable current response value current of the current-dependent overload release | operational current rated value | response value current of instantaneous short-circuit trip unit |
|---|---|---|---|---|---|
| 3RV2021-1EA10 | 4 A | 328.6 g | 2.8 ... 4 A | 4 A | 52 A |
| 3RV2021-1DA25 | 3.2 A | 391.6 g | 2.2 ... 3.2 A | 3.2 A | 42 A |
| 3RV2021-1DA20-Z X95 | 3.2 A | 380.6 g | 2.2 ... 3.2 A | 3.2 A | 42 A |
| 3RV2021-1CA25 | 2.5 A | 392.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2021-1CA20-0BA0 | 2.5 A | 0.377 kg | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2021-1CA20-Z X95 | 2.5 A | 372.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1CA10-0BA0 | 2.5 A | 321.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1CA10-Z X95 | 2.5 A | 323.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1CA10-Z W97 | 2.5 A | 323.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1CA10-Z W96 | 2.5 A | 323.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1CA10 | 2.5 A | 323.6 g | 1.8 ... 2.5 A | 2.5 A | 33 A |
| 3RV2011-1BA25-Z X95 | 2 A | 356.6 g | 1.4 ... 2 A | 2 A | 26 A |
| 3RV2032-4UA15 | 40 A | 1.153 kg | 32 ... 40 A | 40 A | 585 A |
| 3RV2411-1JA20-0DA0 | 10 A | 353.6 g | 7 ... 10 A | 10 A | 208 A |
| 3RV2411-1JA20 | 10 A | 351.6 g | 7 ... 10 A | 10 A | 208 A |
| 3RV2411-1JA15 | 10 A | 347.18 g | 7 ... 10 A | 10 A | 208 A |
| 3RV2411-1JA10-0BA0 | 10 A | 0.336 kg | 7 ... 10 A | 10 A | 208 A |
| 3RV2411-1JA10 | 10 A | 330.6 g | 7 ... 10 A | 10 A | 208 A |
| 3RV2411-1HA20-0DA0 | 8 A | 344.6 g | 5.5 ... 8 A | 8 A | 163 A |
| 3RV2411-1HA20 | 8 A | 345.6 g | 5.5 ... 8 A | 8 A | 163 A |
| 3RV2321-4AC20 | 16 A | 386.6 g | — | 16 A | 208 A |
| 3RV2321-1AC10 | 1.6 A | 0.325 kg | — | 1.6 A | 21 A |
| 3RV2311-4AC20-0BA0 | 16 A | 0.347 kg | — | 16 A | 208 A |
| 3RV2311-4AC20 | 16 A | 348.6 g | — | 16 A | 208 A |
Common to all listed parts
| Product equipment of circuit breaker for motor protection complete unit with protection device | Yes |
| product function disconnector functionality | Yes |
| product extension auxiliary switch | Yes |
| type of calculation of power loss current-dependent | quadratic |
| insulation voltage with degree of pollution 3 at AC rated value | 690 V |
| surge voltage resistance rated value | 6 kV |
| reference code according to IEC 81346-2 | Q |
| installation altitude at height above sea level maximum | 2 000 m |
