Hinge Parts
Compare Hinge
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Dimension A [mm] [mm] | Dimension B [mm] [mm] | Profile P1 [mm] | Profile P2 [mm] | Weight [kg] |
|---|---|---|---|---|---|
| 3842554472 | 60 | 60 | 60 | 60 | 0.11 |
| 3842554470 | 45 | 60 | 45 | 60 | 0.1 |
| 3842564130 | — | — | 45 | 45 | 0.16 |
| 3842554468 | 45 | 45 | 45 | 45 | 0.1 |
| 3842554466 | — | — | 40/50 | 40/50 | 0.09 |
| 3842554458 | 30 | 30 | 30 | 30 | 0.07 |
| 3842554464 | 30 | 60 | 30 | 60 | 0.09 |
| 3842554462 | 30 | 45 | 30 | 45 | 0.08 |
| 3842554460 | 30 | — | 30 | 40/50 | 0.08 |
| 3842564133 | — | — | 30 | 30 | 0.12 |
| 3842543328 | 40 | 40 | 45 | 45 | 0.08 |
| 3842543321 | 40 | 40 | 45 | 45 | 0.08 |
| 3842544531 | 40 | 40 | 45 | 45 | 0.11 |
| 3842543330 | 28 | 40 | 30 | 45 | 0.07 |
| 3842543323 | 28 | 40 | 30 | 45 | 0.07 |
| 3842543329 | 37 | 37 | 40 | 40 | 0.08 |
| 3842543322 | 37 | 37 | 40 | 40 | 0.08 |
| 3842544530 | 37 | 37 | 40 | 40 | 0.1 |
| 3842543331 | 28 | 37 | 30 | 40 | 0.07 |
| 3842543324 | 28 | 37 | 30 | 40 | 0.07 |
| 3842544529 | 28 | 40 | 30 | 45 | 0.09 |
| 3842544528 | 28 | 37 | 30 | 40 | 0.09 |
| 3842543332 | 28 | 28 | 30 | 30 | 0.06 |
| 3842543325 | 28 | 28 | 30 | 30 | 0.06 |
Common to all listed parts
| Packaging unit | 2 |
| Scope of delivery | Incl. fastening material |
