Precision steel shafts with shaft support rails Parts
























Compare Precision steel shafts with shaft support rails
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Tolerance grade shaft | Mass m (kg/m) [kg/m] | Dimension A (profiled rail systems) [mm] | Dimension H [mm] |
|---|---|---|---|---|---|
| R101403060 | 30.0 | h6 | 7.9 | 69 | 42.0 |
| R101403000 | 30.0 | h6 | 7.9 | 69 | 42.0 |
| R101303031 | 30.0 | h7 | 6.3 | 23 | 30.0 |
| R101303061 | 30.0 | h7 | 6.3 | 23 | 30.0 |
| R101303001 | 30.0 | h7 | 6.3 | 23 | 30.0 |
| R101303030 | 30.0 | h6 | 6.3 | 23 | 30.0 |
| R101303060 | 30.0 | h6 | 6.3 | 23 | 30.0 |
| R101303000 | 30.0 | h6 | 6.3 | 23 | 30.0 |
| R101602531 | 25.0 | h7 | 5.6 | 21 | 26.0 |
| R101602561 | 25.0 | h7 | 5.6 | 21 | 26.0 |
| R101602501 | 25.0 | h7 | 5.6 | 21 | 26.0 |
| R101602520 | 25.0 | h6 | 5.6 | 21 | 26.0 |
| R101602530 | 25.0 | h6 | 5.6 | 21 | 26.0 |
| R101602560 | 25.0 | h6 | 5.6 | 21 | 26.0 |
| R101602500 | 25.0 | h6 | 5.6 | 21 | 26.0 |
| R101552531 | 25.0 | h7 | 6.3 | — | — |
| R101552561 | 25.0 | h7 | 6.3 | — | — |
| R101552501 | 25.0 | h7 | 6.3 | — | — |
| R101552530 | 25.0 | h6 | 6.3 | — | — |
| R101552560 | 25.0 | h6 | 6.3 | — | — |
| R101552500 | 25.0 | h6 | 6.3 | — | — |
| R101502531 | 25.0 | h7 | 6 | — | — |
| R101502561 | 25.0 | h7 | 6 | — | — |
| R101502501 | 25.0 | h7 | 6 | — | — |
Common to all listed parts
| Weight [kg] | 0 |
