Precision steel shafts Parts
Compare Precision steel shafts
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Tolerance grade shaft | Mass m (kg/m) [kg/m] | Hardness [HRC] |
|---|---|---|---|---|
| R100003020 | 30.0 | h6 | 5.51 | Min. 55 |
| R100003030 | 30.0 | h6 | 5.51 | Min. 54 |
| R100003060 | 30.0 | h6 | 5.51 | min. 60 |
| R100003000 | 30.0 | h6 | 5.51 | min. 60 |
| R100002521 | 5.0 | h7 | 3.83 | Min. 55 |
| R100002531 | 25.0 | h7 | 3.83 | Min. 54 |
| R100002561 | 25.0 | h7 | 3.83 | min. 60 |
| R100002501 | 25.0 | h7 | 3.83 | min. 60 |
| R100002520 | 25.0 | h6 | 3.83 | Min. 55 |
| R100002530 | 25.0 | h6 | 3.83 | Min. 54 |
| R100002560 | 25.0 | h6 | 3.83 | min. 60 |
| R100002500 | 25.0 | h6 | 3.83 | min. 60 |
| R100002401 | 24.0 | h7 | 3.53 | min. 60 |
| R100002400 | 24.0 | h6 | 3.53 | min. 60 |
| R100002201 | 22.0 | h7 | 2.97 | min. 60 |
| R100002200 | 22.0 | h6 | 2.97 | min. 60 |
| R100002021 | 20.0 | h7 | 2.45 | Min. 55 |
| R100002031 | 20.0 | h7 | 2.45 | Min. 54 |
| R100002061 | 20.0 | h7 | 2.45 | min. 60 |
| R100002001 | 20.0 | h7 | 2.45 | min. 60 |
| R100002020 | 20.0 | h6 | 2.45 | Min. 55 |
| R100002030 | 20.0 | h6 | 2.45 | Min. 54 |
| R100002060 | 20.0 | h6 | 2.45 | min. 60 |
| R100002000 | 20.0 | h6 | 2.45 | min. 60 |
Common to all listed parts
| Version of precision steel shaft | Solid shaft |
| Type | Precision steel shaft |
| Weight [kg] | 0 |
| Footnote length L | Regarding geometry and hardness |
| Cylindricity tolerance t2 footnote | Measurement of differences in diameter |
