Precision steel shafts Parts
Compare Precision steel shafts
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Tolerance grade shaft | Mass m (kg/m) [kg/m] | Hardness [HRC] |
|---|---|---|---|---|
| R100000431 | 4.0 | h7 | 0.1 | Min. 54 |
| R100000430 | 4.0 | h6 | 0.1 | Min. 54 |
| R100004501 | 45.0 | h7 | 12.41 | min. 60 |
| R100004500 | 45.0 | h6 | 12.41 | min. 60 |
| R100004021 | 40.0 | h7 | 9.8 | Min. 55 |
| R100004031 | 40.0 | h7 | 9.8 | Min. 54 |
| R100004061 | 40.0 | h7 | 9.8 | min. 60 |
| R100004001 | 40.0 | h7 | 9.8 | min. 60 |
| R100004020 | 40.0 | h6 | 9.8 | Min. 55 |
| R100004030 | 40.0 | h6 | 9.8 | Min. 54 |
| R100004060 | 40.0 | h6 | 9.8 | min. 60 |
| R100004000 | 40.0 | h6 | 9.8 | min. 60 |
| R100000320 | 3.0 | h6 | 0.06 | Min. 55 |
| R100000300 | 3.0 | h6 | 0.06 | min. 60 |
| R100003801 | 38.0 | h7 | 8.85 | min. 60 |
| R100003800 | 38.0 | h6 | 8.85 | min. 60 |
| R100003501 | 35.0 | h7 | 7.5 | min. 60 |
| R100003500 | 35.0 | h6 | 7.5 | min. 60 |
| R100003201 | 32.0 | h7 | 6.27 | min. 60 |
| R100003200 | 32.0 | h6 | 6.27 | min. 60 |
| R100003021 | 30.0 | h7 | 5.51 | Min. 55 |
| R100003031 | 30.0 | h7 | 5.51 | Min. 54 |
| R100003061 | 30.0 | h7 | 5.51 | min. 60 |
| R100003001 | 30.0 | h7 | 5.51 | min. 60 |
Common to all listed parts
| Version of precision steel shaft | Solid shaft |
| Type | Precision steel shaft |
| Weight [kg] | 0 |
| Cylindricity tolerance t2 footnote | Measurement of differences in diameter |
