Linear sets with linear bushings Parts
























Compare Linear sets with linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Dynamic load capacity C [N] | Weight [kg] | Static load capacity C0 [N] | Dimension B (profiled rail systems) [mm] | Dimension V [mm] |
|---|---|---|---|---|---|
| R106581240 | 1020.0 | 0.16 | 490.0 | 32 | 5.5 |
| R106565040 | 14730.0 | 3.26 | 8280.0 | 70 | 14 |
| R106564040 | 10070.0 | 2.37 | 5570.0 | 78 | 12 |
| R106563040 | 5860.0 | 1.26 | 3570.0 | 60 | 10 |
| R106562540 | 5040.0 | 0.87 | 2470.0 | 54 | 9 |
| R106562040 | 2470.0 | 0.45 | 1340.0 | 42 | 8 |
| R106561640 | 1500.0 | 0.25 | 830.0 | 35 | 6.5 |
| R106561240 | 1020.0 | 0.16 | 490.0 | 32 | 5.5 |
| R072355079 | 9250.0 | 0 | 6470.0 | 50.5 | 8.5 |
| R072355089 | 9250.0 | 0 | 6470.0 | 50.5 | 8.5 |
| R072355085 | 9250.0 | 18.3 | 6470.0 | 50.5 | 8.5 |
| R072355080 | 9250.0 | 0.1 | 6470.0 | 50.5 | 8.5 |
| R072355088 | 9250.0 | 0.1 | 6470.0 | 50.5 | 8.5 |
| R072355087 | 9250.0 | 0.1 | 6470.0 | 50.5 | 8.5 |
| R072355069 | 9250.0 | 0 | 6470.0 | 50.5 | 8.5 |
| R072355086 | 9250.0 | 0 | 6470.0 | 50.5 | 8.5 |
| R072354079 | 6320.0 | 0 | 4350.0 | 41.7 | 7 |
| R072354089 | 6320.0 | 0 | 4350.0 | 41.7 | 7 |
| R072354085 | 6320.0 | 0.1 | 4350.0 | 41.7 | 7 |
| R072354080 | 6320.0 | 8.53 | 4350.0 | 41.7 | 7 |
| R072354088 | 6320.0 | 0.1 | 4350.0 | 41.7 | 7 |
| R072354087 | 6320.0 | 15 | 4350.0 | 41.7 | 7 |
| R072354069 | 6320.0 | 0 | 4350.0 | 41.7 | 7 |
| R072354086 | 6320.0 | 0 | 4350.0 | 41.7 | 7 |
Common to all listed parts
| Type | Linear set |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
