Linear bushings Parts
Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Maximum dynamic load capacity Cmax [N] | Outer diameter D [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R065813030 | 30.0 | 2700.0 | 40.0 | 0.09 | 6 |
| R065813040 | 30.0 | 3250.0 | 40.0 | 0.09 | 6 |
| R065803000 | 30.0 | 3250.0 | 40.0 | 0.09 | 6 |
| R065802530 | 25.0 | 2050.0 | 35.0 | 0.07 | 4.5 |
| R065825440 | 25.0 | — | — | 0.07 | — |
| R065822530 | 25.0 | 2050.0 | 35.0 | 0.07 | 4.5 |
| R065822540 | 25.0 | 2930.0 | 35.0 | 0.07 | 4.5 |
| R065812530 | 25.0 | 2050.0 | 35.0 | 0.07 | 4.5 |
| R065812540 | 25.0 | 2930.0 | 35.0 | 0.07 | 4.5 |
| R065802500 | 25.0 | 2930.0 | 35.0 | 0.07 | 4.5 |
| R065802030 | 20.0 | 990.0 | 28.0 | 0.03 | 3 |
| R065825340 | 20.0 | — | — | 0.04 | — |
| R065822030 | 20.0 | 990.0 | 28.0 | 0.04 | 3 |
| R065822040 | 20.0 | 1410.0 | 28.0 | 0.04 | 3 |
| R065812030 | 20.0 | 990.0 | 28.0 | 0.04 | 3 |
| R065812040 | 20.0 | 1410.0 | 28.0 | 0.04 | 3 |
| R065802000 | 20.0 | 1410.0 | 28.0 | 0.04 | 3 |
| R065805200 | 16.0 | — | — | 0.03 | — |
| R065801630 | 16.0 | 780.0 | 24.0 | 0.03 | 2 |
| R065825240 | 16.0 | — | — | 0.03 | — |
| R065821630 | 16.0 | 780.0 | 24.0 | 0.03 | 2 |
| R065821640 | 16.0 | 1120.0 | 24.0 | 0.03 | 2 |
| R065815276 | 16.0 | — | — | 0.03 | — |
| R065811630 | 16.0 | 780.0 | 24.0 | 0.03 | 2 |
Common to all listed parts
| Format of linear bushings | – Closed |
| Series | Compact |
| Footnote breakaway force | One wiper seal: Multiply value with factor 0.5 |
