Low payload class Parts
Compare Low payload class
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Maximum payload | Rated payload | Maximum reach | A5 | A6 |
|---|---|---|---|---|---|
| U4326106 | 12.6 kg | 6 kg | 1843 mm | 430 °/s | 628 °/s |
| U4325208 | 12.6 kg | 6 kg | 1843 mm | 430 °/s | 628 °/s |
| U4326130 | 14.5 kg | 8 kg | 1441 mm | 430 °/s | 628 °/s |
| U1310349 | 14.5 kg | 12 kg | 1813 mm | 430 °/s | 630 °/s |
| U4326838 | 14.3 kg | 10 kg | 1440 mm | 311 °/s | 472 °/s |
| U1310347 | 20 kg | 16 kg | 1612 mm | 430 °/s | 630 °/s |
| U4327045 | 9 kg | 6 kg | 1840 mm | 311 °/s | 472 °/s |
| U4327048 | 9 kg | 6 kg | 1840 mm | 311 °/s | 472 °/s |
| U865876 | — | 16 kg | 1611 mm | 330 °/s | 615 °/s |
| U861555 | — | 6 kg | 1611 mm | 362 °/s | 659 °/s |
| U4327302 | 14.3 kg | 10 kg | 1440 mm | 311 °/s | 472 °/s |
| U1302496 | 20 kg | 16 kg | 1612 mm | 430 °/s | 630 °/s |
| U810111531 | 23.9 kg | 20 kg | 1820 mm | 360 °/s | 550 °/s |
| U1302487 | 20 kg | 16 kg | 1612 mm | 430 °/s | 630 °/s |
| U1310814 | 14.5 kg | 12 kg | 1813 mm | 430 °/s | 630 °/s |
| U1310813 | 14.5 kg | 12 kg | 1813 mm | 430 °/s | 630 °/s |
| U810116339 | 15.7 kg | 12 kg | 1450 mm | 450 °/s | 720 °/s |
| U690529 | — | 16 kg | 1611 mm | 330 °/s | 615 °/s |
Common to all listed parts
| Number of axes | 6 |
