KR IONTEC Parts
Kuka
372998
Kuka
394138
Kuka
332117
Kuka
334818
Kuka
334944
Kuka
409431
Kuka
361189
Kuka
361186
Kuka
332113
Kuka
332115Compare KR IONTEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Maximum payload | Rated payload | Maximum reach | A2 | A3 |
|---|---|---|---|---|---|
| 408224 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| 372998 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| 394138 | 62 kg | 50 kg | 2501 mm | 158 °/s | 175 °/s |
| 332117 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| 334818 | 62 kg | 50 kg | 2501 mm | 158 °/s | 175 °/s |
| 334944 | 24 kg | 20 kg | 3101 mm | 165 °/s | 160 °/s |
| 408221 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| 408222 | 62 kg | 50 kg | 2501 mm | 158 °/s | 175 °/s |
| 409431 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| 361189 | 62 kg | 50 kg | 2501 mm | 158 °/s | 175 °/s |
| 361186 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| 408220 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| 332113 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| 332115 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
Common to all listed parts
| Mounting position | Floor, Ceiling, Wall, Desired angle |
| Pose repeatability (ISO 9283) | 0.05 mm |
| Number of axes | 6 |
| Ambient temperature during operation | 0 °C to 55 °C (273 K to 328 K) |
| Ambient temperature during stor./transp. | -40 °C to 60 °C (233 K to 333 K) |
