Siemens 6ES7332-5TB10-0AB0
Spare part ********* SIMATIC DP, HART analog output, SM 332, 2 AO, 0/4 - 20 mA HART from HART revision 5.0
- MPN
- 6ES7332-5TB10-0AB0
- Category
- CPU & Controllers
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6ES7332-5TB10-0AB0?
********** spare part ********* SIMATIC DP, HART analog output, SM 332, 2 AO, 0/4 - 20 mA HART from HART revision 5.0, for ET200M with IM 153-2, 1 x 20-pole
Specifications
Supply voltage
| Load voltage L+ — Rated value (DC) | 24 V |
| Load voltage L+ — Reverse polarity protection | Yes |
Input current
| from load voltage L+ (without load), max. | 150 mA |
| from backplane bus 5 V DC, max. | 100 mA |
Power loss
| Power loss, typ. | 3.5 W |
Analog outputs
| Number of analog outputs | 2 |
| Current output, no-load voltage, max. | 19 V |
| Cycle time (all channels) max. | 5 ms |
| Output ranges, current — 0 to 20 mA | Yes |
| Output ranges, current — 20 mA to +20 mA | No |
| Output ranges, current — 4 mA to 20 mA | Yes |
| Connection of actuators — for current output two-wire connection | Yes |
| Load impedance (in rated range of output) — with current outputs, max. | 650 Ω |
| Load impedance (in rated range of output) — with current outputs, inductive load, max. | 7.5 mH |
| Destruction limits against externally applied voltages and currents — Voltages at the outputs towards MANA | max. 17 V / -0.5 V |
| Destruction limits against externally applied voltages and currents — Current, max. | 60 mA / -1 A |
| Cable length — shielded, max. | 400 m |
Analog value generation for the outputs
| Integration and conversion time/resolution per channel — Resolution with overrange (bit including sign), max. | 12 bit; + sign |
| Integration and conversion time/resolution per channel — Conversion time (per channel) | 40 ms |
| Settling time — for resistive load | 2.5 ms |
| Settling time — for capacitive load | 4 ms |
| Settling time — for inductive load | 2.5 ms |
Errors/accuracies
| Operational error limit in overall temperature range — Current, relative to output range, (+/-) | 0.55 % |
| Basic error limit (operational limit at 25 °C) — Current, relative to output range, (+/-) | 0.15 % |
Interrupts/diagnostics/status information
| Diagnostics function | Yes; Parameterizable |
| Substitute values connectable | Yes; Parameterizable |
| Alarms — Diagnostic alarm | Yes; Parameterizable |
| Diagnoses — Overrange | Yes |
| Diagnoses — Wire break | Yes; as of output value > 0.5 mA |
| Diagnoses — HART communication active | Yes; green LED (H) |
| Diagnostics indication LED — Group error SF (red) | Yes; red LED |
| Diagnostics indication LED — Channel fault indicator F (red) | Yes; per channel |
Ex(i) characteristics
| Module for Ex(i) protection | Yes |
| maximum values for connecting terminals for gas group IIC — Uo (no-load voltage), max. | 19 V |
| maximum values for connecting terminals for gas group IIC — Io (short-circuit current), max. | 66 mA |
| maximum values for connecting terminals for gas group IIC — Po (power output), max. | 506 mW |
| maximum values for connecting terminals for gas group IIC — Co (permissible external capacity), max. | 230 nF |
| maximum values for connecting terminals for gas group IIC — Lo (permissible external inductivity), max. | 7.5 mH |
| maximum values for connecting terminals for gas group IIC — Um (voltage at non-intrinsically safe connecting terminals), max. | 60 V; DC |
Potential separation
| Potential separation analog outputs — between the channels | Yes |
| Potential separation analog outputs — between the channels and backplane bus | Yes |
| Potential separation analog outputs — Between the channels and load voltage L+ | Yes |
Permissible potential difference
| between the outputs (UCM) | 60 V DC/30 V AC permitted potential difference (Viso) of signals from hazardous areas |
Degree and class of protection
| IP degree of protection | IP20 |
Standards, approvals, certificates
| Use in hazardous areas — ATEX marking | ATEX II 3 G (2) GD Ex nA [ib Gb] [ib IIIC Db] IIC T4 Gc |
| Use in hazardous areas — ATEX certificate | DEKRA 14 ATEX 0053X |
| Use in hazardous areas — FM marking | Class I, Division 2, Group A, B, C, D T4; Class I, Zone 2, Group IIC T4 |
Ambient conditions
| Ambient temperature during operation — max. | 60 °C |
Connection method
| required front connector | 20-pin |
Dimensions
| Width | 40 mm |
| Height | 125 mm |
| Depth | 120 mm |
Weights
| Weight, approx. | 290 g |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
