Siemens
6EP1353-0AA00Siemens 6EP1433-2CA00
SITOP PSU300P/3AC/24VDC/8A/IP67 Spare part: SITOP PSU300P 8 A stabilized power supply in degree of protection…
- MPN
- 6EP1433-2CA00
- Category
- Power Supplies
Price and lead time confirmed within 1 business day
Discontinued by Siemens — we can still source the original 6EP1433-2CA00 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Siemens 6EP1433-2CA00?
SITOP PSU300P/3AC/24VDC/8A/IP67 ********** spare part ********* SITOP PSU300P 8 A stabilized power supply in degree of protection IP67 input: 400-480 V 3 AC output: 24 V DC/8 A
Specifications
General information
| Technical Product Detail Page | https://i.siemens.com/1P6EP1433-2CA00 |
| product brand name | SITOP PSU300P |
| product designation | Power supply SITOP |
| type of current supply | 24 V/8 A |
input
| type of the power supply network | 3-phase AC |
| phase number | 3 |
| voltage curve at input | AC |
| supply voltage at AC — minimum rated value | 400 V |
| supply voltage at AC — maximum rated value | 480 V |
| supply voltage at AC — initial value | 340 V |
| supply voltage at AC — full-scale value | 550 V |
| supply voltage at AC | 320 ... 340 V for max. 1 min |
| supply voltage — at 50 Hz | 400 V |
| supply voltage — at 60 Hz | 480 V |
| line frequency | 50/60 Hz |
| line frequency | 45 ... 66 Hz |
| wide range input | Yes |
| overvoltage overload capability | Implemented internally with varistors |
| buffering time for rated value of the output current in the event of power failure minimum | 15 ms |
| operating condition of the mains buffering | at Vin = 400 V |
| input current — at rated input voltage 400 V | 0.5 A |
| current limitation of inrush current at 25 °C maximum | 40 A |
| I2t value maximum | 3.5 A²·s |
| fuse protection type | T 4 A |
| fuse protection type in the feeder | Required: Circuit breaker 3RV2011-1DA10 or 3RV2711-1DD10 (UL 489) |
output
| voltage curve at output | Controlled, isolated DC voltage |
| product function output voltage controlled | Yes |
| product function output voltage stabilized | Yes |
| output voltage at DC rated value | 24 V |
| output voltage — at output 1 at DC rated value | 24 V |
| output voltage — at output 1 at DC | 24 V |
| output voltage adjustable | No; - |
| relative overall tolerance of the voltage | 3 % |
| relative control precision of the output voltage — on slow fluctuation of input voltage | 0.5 % |
| relative control precision of the output voltage — on slow fluctuation of ohm loading | 0.5 % |
| residual ripple — maximum | 200 mV |
| voltage peak — maximum | 250 mV |
| display version for normal operation | Green LED for 24 V OK |
| type of signal at output | max. 30 V, 10 mA; Power-Good (High-Pegel 1L+ for Vout in range 21.3 ... 29 V); Overtemperature warning at least 30 s before switch-off (high level 1L+ when the max. internal temperature is exceeded) |
| behavior of the output voltage when switching on | Overshoot of Vout < 2 % |
| response delay maximum | 1.5 s |
| voltage increase time of the output voltage — typical | 40 ms |
| output current — rated value | 8 A |
| output current — rated range | 0 ... 8 A |
| supplied active power typical | 192 W |
| short-term overload current — on short-circuiting during the start-up typical | 50 A |
| short-term overload current — at short-circuit during operation typical | 50 A |
| duration of overloading capability for excess current — on short-circuiting during the start-up | 100 ms |
| duration of overloading capability for excess current — at short-circuit during operation | 100 ms |
| bridging of equipment | No |
efficiency
| efficiency in percent | 88 % |
| power loss [W] — at rated output voltage for rated value of the output current typical | 25 W |
closed-loop control
| relative control precision of the output voltage with rapid fluctuation of the input voltage by +/- 15% typical | 0.5 % |
| relative control precision of the output voltage load step of resistive load 50/100/50 % typical | 1 % |
| setting time — maximum | 2 ms |
protection and monitoring
| design of the overvoltage protection | < 33 V |
| property of the output short-circuit proof | Yes |
| design of short-circuit protection | Electronic shutdown, automatic restart |
| typical | 9.4 A |
| enduring short circuit current RMS value — maximum | 10 A |
safety
| galvanic isolation between input and output | Yes |
| galvanic isolation | Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178 |
| operating resource protection class | Class I |
| leakage current — maximum | 3.5 mA |
| leakage current — typical | 0.4 mA |
| protection class IP | IP67, enclosure type 5 indoor |
EMC
| standard — for emitted interference | EN 55022 Class A |
| standard — for mains harmonics limitation | - |
| standard — for interference immunity | EN 61000-6-2 |
standards, specifications, approvals
| certificate of suitability — CE marking | Yes |
| certificate of suitability — UL approval | Yes; UL-Listed (UL 508) according to NFPA compatibility (National Fire Protection Association), see operating instructions |
| certificate of suitability — EAC approval | Yes |
| certificate of suitability — NEC Class 2 | No |
| type of certification — CB-certificate | Yes |
standards, specifications, approvals hazardous environments
| certificate of suitability — IECEx | No |
| certificate of suitability — ATEX | No |
| certificate of suitability — ULhazloc approval | No |
| certificate of suitability — FM registration | No |
standards, specifications, approvals marine classification
| shipbuilding approval | No |
| Marine classification association — American Bureau of Shipping Europe Ltd. (ABS) | No |
| Marine classification association — French marine classification society (BV) | No |
| Marine classification association — Det Norske Veritas (DNV) | No |
| Marine classification association — Lloyds Register of Shipping (LRS) | No |
ambient conditions
| ambient temperature — during operation | -25 ... +55 °C; with natural convection |
| ambient temperature — during transport | -40 ... +70 °C |
| ambient temperature — during storage | -40 ... +70 °C |
| environmental category according to IEC 60721 | Climate class 3K3, 5 ... 95% no condensation |
connection method
| type of electrical connection | screw terminal |
| at input | L1, L2, L3, PE: Plug connector HAN Q4/2 (counterpart see "Electrical accessories") |
| at output | L+, M: 1 x 2 mm² each (2-pole cable for +/- with open, labeled ends, 2 x 2 mm²) |
| for auxiliary contacts | Alarm signals: M12 plug-in connector 5-pin |
mechanical data
| width × height × depth of the enclosure | 310 × 135 × 90 mm |
| fastening method | Can be mounted onto ET200pro mounting rail |
| DIN-rail mounting | No |
| S7 rail mounting | No |
| wall mounting | Yes |
| housing can be lined up | No |
| net weight | 2.8 kg |
accessories
| electrical accessories | Power connector (3RK1911-2BE50 (2.5mm²)) |
further information internet links
| internet link — to website: Industry Mall | https://mall.industry.siemens.com |
| internet link — to web page: selection aid TIA Selection Tool | https://www.siemens.com/tstcloud |
| internet link — to website: CAx-Download-Manager | https://siemens.com/cax |
| internet link — to website: Industry Online Support | https://support.industry.siemens.com |
additional information
| other information | Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified) |
security information
| security information | Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7) |
