Siemens 3TX7462-3S
Surge suppressor RC element for snapping on 48-127 V AC for contactors size 3...6
- MPN
- 3TX7462-3S
- Category
- Accessories for 3TC contactors
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3TX7462-3S?
Surge suppressor RC element for snapping on 48-127 V AC for contactors size 3...6
Specifications
General
| product category | Surge suppressor |
| product designation | RC element |
| product type designation | 3TX7 |
| suitability for use | for 3T.4, 3T.5 contactors |
General technical data
| certificate of suitability | CE / UL / CSA |
| Substance Prohibitance (day/month/year) | 07/01/2006 |
| SVHC substance name | Triphenyl phosphate CAS-No. 115-86-6 |
| Net Weight | 0.09 kg |
| type of voltage of the control supply voltage | AC/DC |
| control supply voltage at AC — at 50 Hz rated value | 48 ... 127 V |
| control supply voltage at AC — at 60 Hz rated value | 48 ... 127 V |
| control supply voltage frequency — 1 rated value | 50 Hz |
| control supply voltage frequency — 2 rated value | 60 Hz |
| control supply voltage at DC rated value | 70 ... 150 V |
| design of the surge suppressor | RC element |
Ambient conditions
| ambient temperature — during operation | -25 ... +55 °C |
| ambient temperature — during storage | -40 ... +80 °C |
