Siemens 3RG9004-0DA00
AS-Interface module F90, digital 4 DI/4 DQ, IP20 4 x inputs for 3-wire sensor 4 x output, 2 A
- MPN
- 3RG9004-0DA00
- Category
- F90 module
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3RG9004-0DA00?
AS-Interface module F90, digital 4 DI/4 DQ, IP20 4 x inputs for 3-wire sensor 4 x output, 2 A, 24 V DC maximal 6 A for all outputs Connection via Combicon Width 90 mm Combicon connector set 3RX9810-0AA00 must be ordered .
Specifications
General technical data
| design of the product | F90 module - I/O modules for operation in the control cabinet, IP20 |
| design of the device type | standard slave |
| type of electrical connection of the inputs and outputs | combicon connection |
Sensor supply
| type of voltage supply for sensor supply | using AS-Interface |
| property of the sensor supply short-circuit and overload resistant | Yes |
| ampacity of the sensor supply for all inputs at ambient temperature 40 °C | 200 mA |
Inputs
| number of digital inputs | 4 |
| type of connection technology | 2- and 3-conductor PNP transistor |
| type of voltage of the input voltages | DC |
| input current at digital input — for signal <1> minimum | 5 mA |
| input current at digital input — with signal <0> maximum | 1.5 mA |
Outputs
| number of digital outputs | 4 |
| type of voltage of output voltages | DC |
| output current at digital output for signal <1> rated value | 2 A |
| type of switching output | solid state |
| property of the output short-circuit proof | Yes |
Ambient conditions
| ambient temperature — during operation | -25 ... +70 °C |
| ambient temperature — during storage | -40 ... +85 °C |
| protection class IP | IP20 |
Mechanical data
| width | 90 mm |
| height | 75 mm |
| depth | 37 mm |
| fastening method | 35 mm standard rail mounting |
