Siemens 3RG9002-0DC00
AS-Interface module F90, digital 4 DI/4 DQ
- MPN
- 3RG9002-0DC00
- Category
- F90 module
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3RG9002-0DC00?
AS-Interface module F90, digital 4 DI/4 DQ, IP20 4 x inputs for 3-wire sensor External sensor supply 4 x output, 2 A, 24 V DC maximal 6 A for all outputs Connection via screw terminals Width 90 mm
Specifications
General technical data
| design of the product | F90 module - I/O modules for operation in the control cabinet, IP20 |
| design of the device type | standard slave |
| type of electrical connection of the inputs and outputs | screw-type terminals |
Sensor supply
| type of voltage supply for sensor supply | via AUX POWER |
| property of the sensor supply short-circuit and overload resistant | Yes |
| ampacity of the sensor supply for all inputs at ambient temperature 40 °C | 200 mA |
Inputs
| number of digital inputs | 4 |
| type of connection technology | 2- and 3-conductor PNP transistor, floating |
| type of voltage of the input voltages | DC |
| input current at digital input — for signal <1> minimum | 5 mA |
| input current at digital input — with signal <0> maximum | 1.5 mA |
Outputs
| number of digital outputs | 4 |
| type of voltage of output voltages | DC |
| output current at digital output for signal <1> rated value | 2 A |
| type of switching output | solid state |
| property of the output short-circuit proof | Yes |
Ambient conditions
| ambient temperature — during operation | -25 ... +70 °C |
| ambient temperature — during storage | -40 ... +85 °C |
| protection class IP | IP20 |
Mechanical data
| width | 90 mm |
| height | 75 mm |
| depth | 37 mm |
| fastening method | 35 mm standard rail mounting |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
3RG9002-0DC00: frequently asked questions
When can 3RG9002-0DC00 be shipped?
3RG9002-0DC00 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3RG9002-0DC00 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3RG9002-0DC00 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3RG9002-0DC00, subject to availability and destination.
