Schneider Electric TSXP57154M
Unity processor - 2 racks (12 slots) / 4 racks (4/6/8 slots) - 930 mA, 5 V DC
- MPN
- TSXP57154M
- EAN
- 3595863810028
- Category
- Modicon Premium
Price and lead time confirmed within 1 business day
Discontinued by Schneider Electric — we can still source the original TSXP57154M (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric TSXP57154M?
Schneider Electric TSXP57154M — Unity processor - 2 racks (12 slots) / 4 racks (4/6/8 slots) - 930 mA, 5 V DC (Modicon Premium). Discontinued by Schneider Electric; the manufacturer's successor is BMEP581020. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Unity processor |
| Software designation | Unity Pro |
Complementary
| Number of racks | 2 12 slots; 4 4/6/8 slots |
| Number of slots | 24; 16; 32 |
| Discrete I/O processor capacity | 512 I/O |
| Analogue I/O processor capacity | 24 I/O |
| Number of application specific channel | 8 |
| Integrated connection type | Non isolated serial link 2 female mini DIN connector (RS485) (19.2 kbit/s); Fipio manager (63 agents) SUB-D 9 connector |
| Communication module processor capacity | 2; 1 |
| Memory description | Internal RAM (with PCMCIA card) 224 kB program; Internal RAM (with PCMCIA card) 96 kB data; Internal RAM (without PCMCIA card) 96 kB program and data; PCMCIA card 256 kB additional data storage |
| Maximum size of object areas | 32 kB (elementary and derived data) unlocated internal data; 4096 %Mi located internal bits; 64 %KWi constant words located internal data; 64 %MWi internal words located internal data; 64 kB (DFB and EFB function blocks) unlocated internal data |
| Application structure | 1 master task; 1 fast task; 32 event tasks |
| Execution time per instruction | 0.19 µs Boolean without PCMCIA card; 0.25 µs Boolean with PCMCIA card; 0.25 µs word or fixed-point arithmetic without PCMCIA card; 0.5 µs word or fixed-point arithmetic with PCMCIA card; 1.75...2.6 µs floating points with PCMCIA card; 1.75...2.6 µs floating points without PCMCIA card |
| Number of instructions per ms | 2.1 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card; 3.1 Kinst/ms 100 % Boolean with PCMCIA card; 3.71 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card; 4.76 Kinst/ms 100 % Boolean without PCMCIA card |
| System overhead | 0.3 ms for fast task; 1 ms for master task |
| Marking | CE |
| Local signalling | 1 LED (green) for processor running (RUN); 1 LED (red) for activity on Fipio bus (FIP); 1 LED (red) for I/O module or configuration fault (I/O); 1 LED (red) for processor or system fault (ERR); 1 LED (yellow) for activity on TER or AUX terminal port (TER) |
| Current consumption | 930 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.42 kg |
Environment
| Standards | IEC 61131-2; CSA C22.2 No 213 Class I Division 2 Group C; CSA C22.2 No 142; 73/23/EEC; CSA C22.2 No 213 Class I Division 2 Group A; CSA C22.2 No 213 Class I Division 2 Group D; 93/68/EEC; 92/31/EEC; CSA C22.2 No 213 Class I Division 2 Group B; UL 508; 89/336/EEC |
| Product certifications | GL; RMRS; RINA; DNV; ABS; LR; BV |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
No matching specifications
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
TSXP57154M: frequently asked questions
Can I still buy the TSXP57154M now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXP57154M, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMEP581020 as its successor — we can quote both.
When can TSXP57154M be shipped?
TSXP57154M is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXP57154M in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXP57154M and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXP57154M, subject to availability and destination.
