Schneider Electric TSXAEY1614C – analog input module - 16 inputs - thermocouple - 16 bits

Name: Schneider Electric TSXAEY1614C – analog input module - 16 inputs - thermocouple - 16 bits
Brand: Schneider Electric
SKU: TSXAEY1614C

MPN: TSXAEY1614C · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original TSXAEY1614C (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon Premium
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
UPC / EAN	3595863938999
Recommended replacement	BMXART0814H
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the TSXAEY1614C now that it is discontinued?

Yes. Schneider Electric has discontinued the TSXAEY1614C, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXART0814H as its successor — we can quote both.

When can TSXAEY1614C be shipped?

TSXAEY1614C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TSXAEY1614C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TSXAEY1614C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXAEY1614C, subject to availability and destination.

Schneider Electric TSXAEY1614C — analog input module - 16 inputs - thermocouple - 16 bits (Modicon Premium). Discontinued by Schneider Electric; the manufacturer's successor is BMXART0814H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Premium Automation platform
Product or component type	Analog input module
Analogue input number	16
Analogue input type	Thermocouple thermocouple B; Thermocouple thermocouple E; Thermocouple thermocouple J; Thermocouple thermocouple K; Thermocouple thermocouple L; Thermocouple thermocouple N; Thermocouple thermocouple R; Thermocouple thermocouple S; Thermocouple thermocouple T; Thermocouple thermocouple U; Voltage +/- 80 mV
Analog/digital conversion	16 bits

Complementary

Nominal read cycle time	70 ms per channel
Measurement error	0.8 °C thermocouple E 25 °C; 0.9 °C thermocouple J 25 °C; 0.9 °C thermocouple L 25 °C; 1 °C thermocouple K 25 °C; 1 °C thermocouple T 25 °C; 1 °C thermocouple U 25 °C; 1.1 °C thermocouple N 25 °C; 1.2 °C thermocouple E 0...60 °C; 1.3 °C thermocouple T 0...60 °C; 1.3 °C thermocouple U 0...60 °C; 1.4 °C thermocouple J 0...60 °C; 1.4 °C thermocouple L 0...60 °C; 1.6 °C thermocouple K 0...60 °C; 1.7 °C thermocouple N 0...60 °C; 2.1 °C thermocouple R 25 °C; 2.2 °C thermocouple S 25 °C; 2.4 °C thermocouple R 0...60 °C; 2.5 °C thermocouple B 25 °C; 3.7 °C thermocouple S 0...60 °C; 4 °C thermocouple B 0...60 °C
Isolation between channels and bus	1000 Vrms
Isolation between channels and ground	1000 Vrms
Common mode between channels	250 V AC or 280 V AC
Common mode between channels and earth	250 V DC
Input overvoltage protection	-15…15 V at state 0 250 Ohm; -30…30 V at state 1 250 Ohm
Electrical connection	2 connectors SUB-D 25
Overcurrent	-30…30 mA at state 1 250 kOhm
Marking	CE
Current consumption	300 mA at 5 V DC
Module format	Standard
Net weight	0.35 kg

Environment

Standards	IEC 751; DIN 43760; IEC 584; DIN 43710; NFC 42-330; IEC 1131
Product certifications	GL; RINA; LR; RMRS; BV; ABS; DNV
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-25…70 °C
Relative humidity	10…95 % without condensation for operation; 5…95 % without condensation for storage
Operating altitude	0...2000 m
Protective treatment	Conformal coating Humiseal 1A33; TC
IP degree of protection	IP20
Pollution degree	2
