Schneider Electric TSXAEY1614
Analog input module Modicon Premium - 16 I thermocouple ± 63 mV
- MPN
- TSXAEY1614
- EAN
- 3389110876321
- Category
- Modicon Premium
Price and lead time confirmed within 1 business day
Discontinued by Schneider Electric — we can still source the original TSXAEY1614 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric TSXAEY1614?
Schneider Electric TSXAEY1614 — analog input module Modicon Premium - 16 I thermocouple ± 63 mV. Discontinued by Schneider Electric; the manufacturer's successor is BMXART0814. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Analog input module |
| Analogue input number | 16 |
| Analogue input type | Thermocouple thermocouple B; Thermocouple thermocouple E; Thermocouple thermocouple J; Thermocouple thermocouple K; Thermocouple thermocouple L; Thermocouple thermocouple N; Thermocouple thermocouple R; Thermocouple thermocouple S; Thermocouple thermocouple T; Thermocouple thermocouple U; Voltage +/- 80 mV |
| Analog/digital conversion | 16 bits |
Complementary
| Nominal read cycle time | 70 ms per channel |
| Measurement error | 0.8 °C thermocouple E 25 °C; 0.9 °C thermocouple J 25 °C; 0.9 °C thermocouple L 25 °C; 1 °C thermocouple K 25 °C; 1 °C thermocouple T 25 °C; 1 °C thermocouple U 25 °C; 1.1 °C thermocouple N 25 °C; 1.2 °C thermocouple E 0...60 °C; 1.3 °C thermocouple T 0...60 °C; 1.3 °C thermocouple U 0...60 °C; 1.4 °C thermocouple J 0...60 °C; 1.4 °C thermocouple L 0...60 °C; 1.6 °C thermocouple K 0...60 °C; 1.7 °C thermocouple N 0...60 °C; 2.1 °C thermocouple R 25 °C; 2.2 °C thermocouple S 25 °C; 2.4 °C thermocouple R 0...60 °C; 2.5 °C thermocouple B 25 °C; 3.7 °C thermocouple S 0...60 °C; 4 °C thermocouple B 0...60 °C |
| Isolation between channels and bus | 1000 Vrms |
| Isolation between channels and ground | 1000 Vrms |
| Common mode between channels | 250 V AC or 280 V AC |
| Common mode between channels and earth | 250 V DC |
| Input overvoltage protection | -15…15 V at state 0 250 Ohm; -30…30 V at state 1 250 Ohm |
| Electrical connection | 2 connectors SUB-D 25 |
| Overcurrent | -30…30 mA at state 1 250 kOhm |
| Marking | CE |
| Current consumption | 300 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.35 kg |
Environment
| Standards | NFC 42-330; IEC 1131; DIN 43710; IEC 751; DIN 43760; IEC 584 |
| Product certifications | DNV; RMRS; LR; ABS; RINA; BV; GL |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
