Schneider Electric RGZE1S48M
Socket with clamp, Harmony Electromechanical Relays, for RXG2 relays, 5A, screw connec to rs, separate contact
- MPN
- RGZE1S48M
- EAN
- 3606480689444
- Category
- Harmony Electromechanical Relays
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric RGZE1S48M?
"This Harmony RGZ timing relay socket has separate contact terminals." "It enables quick and easy plug-in installation of relays without the need for tools." "It is compatible with all 2 C/O DPDT RXG relays." "Simple relay retention via clamp allows quick replacement of relays and minimizes machine downtime."
Specifications
Specifications
| Range of product | Harmony Electromechanical Relays |
| Product or component type | Socket |
| Product compatibility | Plug-in relay RXG with 2 C/O contact |
| Contacts type and composition | 2 C/O |
| [Ui] rated insulation voltage | 250 V |
| [Uimp] rated impulse withstand voltage | 6 kV between coil and contact with reinforced insulation, 4 kV between poles with basic insulation, 4 kV between terminals and DIN rail with basic insulation |
| [Ue] rated operational voltage | 250 V conforming to IEC, 300 V conforming to UL |
| Dielectric strength | 5 kV between coil and contact with reinforced insulation, 3 kV between poles with basic insulation, 3 kV between terminals and DIN rail with basic insulation |
| Connections - terminals | Screw terminals, 1 x 0.34...1 x 2.5 mm² (AWG 22...AWG 14) flexible with cable end, Screw terminals, 2 x 0.34...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end, Screw terminals, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end, Screw terminals, 1 x 0.5...1 x 2.5 mm² (AWG 20...AWG 14) solid without cable end |
| Fixing mode | Screw (panel), Clip-on (35 mm symmetrical DIN rail) |
| Wire stripping length | 6…7 mm |
| Contact terminal arrangement | Separate |
| screw type | M3 |
| Overvoltage category | III |
| Pollution degree | 3 |
| Standards | CSA C22.2 No 14, IEC 61984, UL 508 |
| Product certifications | EAC, CE, CSA, UL, DNV-GL |
| Ambient air temperature for storage | -40…85 °C |
| Ambient air temperature for operation | -40…70 °C |
| IP degree of protection | IP20 |
| Relative humidity | 10…85 % |
Packaging
| Package 1 | 1 PCE, 7.900 cm × 6.800 cm × 1.600 cm (L × W × H), 40.000 g |
| Package 2 | 10 BB1, 16.500 cm × 8.600 cm × 8.500 cm (L × W × H), 444.000 g |
| Package 3 | 180 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 8.544 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
RGZE1S48M: frequently asked questions
When can RGZE1S48M be shipped?
RGZE1S48M is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up RGZE1S48M in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for RGZE1S48M and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for RGZE1S48M, subject to availability and destination.
