Schneider Electric NSYPHDT553P
Thalassa PHD outdoor heavy duty - enclosure H538 W500 D320 IP65 plain door
- MPN
- NSYPHDT553P
- EAN
- 3606480675980
- Category
- PanelSeT for outdoors operation
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYPHDT553P?
Schneider Electric Thalassa PHD outdoor heavy duty - enclosure H538 W500 D320 IP65 plain door, manufacturer part number NSYPHDT553P. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range | PanelSeT |
| Product | PHD |
| Application | Outdoor heavy duty |
| Certification | UL conforming to UL 508 A 2007, Bureau Veritas conforming to IEC 61969-3 2011, Bureau Veritas conforming to IEC 61439-5 2010, DEKRA conforming to IEC 62208 2011 |
| Enclosure type | Multi-purpose |
| Category | Suitable enclosure |
| Version | PHDT |
| Enclosure height with canopy | 538 mm |
| Canopy height | 38 mm |
| Enclosure width | 500 mm |
| Enclosure depth | 320 mm |
| Enclosure mounting | Wall mounted |
| Device composition | 1 body in polyester double reinforced with fibreglass, 1 door in polyester double reinforced with fibreglass, 1 canopy in polyester double reinforced with fibreglass, 1 door retainer in steel with anti-corrosive coating, 1 document pocket in plastic A4 format |
| Body type | Sealed assembled body |
| Door type | Plain |
| Number of doors | 1 door(s) |
| Door opening side | Right or left (120 °) |
| Lock type | 2 points lock, handle with 1242E key lock and padlock |
| Accessibility for operation | Front |
| Maximum static load | 180 kg |
| Removable parts | Door by hinges |
| Material | Polyester double reinforced with fibreglass |
| Colour | Grey (RAL 7035) |
| Standards | IEC 62208, UL 508 A, IEC 61439-5, IEC 61969-3 |
| Electrical insulation class | Class II conforming to IEC 61439-1 2011 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| IK degree of protection | IK10 conforming to IEC 62262 (plain door) |
| Mechanical robustness | Vandal-proof conforming to EN/IEC 61439-5 version 2010 |
| Fire resistance | 960 °C conforming to IEC 62208 |
| Ambient air temperature for operation | -45…80 °C conforming to IEC 61969-3 class 1 |
| Ambient air temperature for storage | -25…40 °C |
| Corrosion withstand | 90…100 % conforming to ISO 12944 C4H |
| Environmental withstand | Solar radiation: class 1 up to 1120 W/m² conforming to IEC 61969-3:2011, Surrounding air withstand: class 1 up to 180 km/h conforming to IEC 61969-3:2011, Ultraviolet degradation test: class 1 conforming to ISO 4892-2:2013, Formation of ice and frost: class 1 conforming to IEC 61969-3:2011, Fauna and flora withstand: class 1 conforming to IEC 61969-3:2011, : class 1 conforming to IEC 61969-3:2011 |
| Thermal management options | Natural: 269 W at -25 °C, Natural: 117 W at 20 °C, Natural: 50 W at 40 °C, Fan: 1500 W for a maximum noise level of 60 dB |
Packaging
| Package 1 | 1 PCE, 35.000 cm × 53.000 cm × 54.000 cm (L × W × H), 15.500 kg |
| Package 2 | 15 PAM, 120.000 cm × 100.000 cm × 176.000 cm (L × W × H), 245.000 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYPHDT553P: frequently asked questions
When can NSYPHDT553P be shipped?
NSYPHDT553P is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYPHDT553P in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYPHDT553P and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYPHDT553P, subject to availability and destination.
