Schneider Electric NSYMD33
Symmetrical mounting chassis (4 rails) for enclosure dimensions H300xW300mm
- MPN
- NSYMD33
- EAN
- 3606480182815
- Category
- PanelSeT CRN
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYMD33?
Set of 1 symmetrical DIN rails for equipment to be used in PanelSeT CRN, PanelSeT S3D, PanelSeT S3X and PanelSeT PLM enclosures The chassis is made from aluminium uprights and steel rail Suitable for enclosures of 300mm width, 300mm height and 150mm depth The nominal width is 300mm and real width is 250mm The real depth is 30mm The nominal height is 300mm and real height is 239,3mm Fixed with a pitch of 12mm The kit is made up of fixing elements, 2 uprights and 4 DIN rails
Specifications
Specifications
| Anwendung | Multi-purpose |
| Range | PanelSeT |
| Product or component type | Chassis |
| Accessory / separate part category | Mounting accessory |
| Type of rail | Symmetrical DIN |
| Enclosure nominal dimensions | - H: 300 mm W: 300 mm D: 150 mm, - H: 300 mm W: 300 mm D: 200 mm |
| Mounting support | Direct fixing on backstuds, Spacer, Step slide |
| Range compatibility | PanelSeT CRN, PanelSeT S3D, PanelSeT PLM |
| Device composition | Fixing elements, 2 upright, 4 DIN rail |
| Quantity per set | Set of 1 |
| Material | Uprights: aluminium, Rail: steel |
| Fixing mode | Screwed on backstuds, By fixing element |
| Adjustment | On step slides, type NSYSDCR…, pitch 12.5 mm |
| Height | Nominal: 300 mm, Real: 239.3 mm |
| Width | Nominal: 300 mm, Real: 250 mm |
| Depth | Real : 30 mm |
Packaging
| Package 1 | 1 PCE, 31.000 cm × 10.000 cm × 4.000 cm (L × W × H), 624.000 g |
| Package 2 | 300 PAM, 120.000 cm × 100.000 cm × 45.000 cm (L × W × H), 200.000 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYMD33: frequently asked questions
When can NSYMD33 be shipped?
NSYMD33 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYMD33 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYMD33 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYMD33, subject to availability and destination.
