Schneider Electric LXM62PD20A11000 – Lexium LXM 62 power supply drive - 10/20 A

MPN: LXM62PD20A11000 · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Lexium 62 & Motors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3606485400341
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can LXM62PD20A11000 be shipped?

LXM62PD20A11000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up LXM62PD20A11000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for LXM62PD20A11000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LXM62PD20A11000, subject to availability and destination.

This product is part of the PacDrive 3 range, an offer of power supplies for integrated drives. The power supply module features SERCOS III communication interface. It offers 2 relay outputs for volt-free contacts. It is a power supply module with a rated supply voltage of 400V three phase, 230V three/single phase and a rated supply current of 10A single/three phase AC. It is an IP20 rated product. Its dimensions are 89.5mm (width) x 270mm (depth) x 310mm (height). It weighs 6.3kg. It is suitable for use in general machine control, packaging machine automation, material handling applications. This product is certified by CE and CSA. It meets EN/IEC 61800-5-1, EN/IEC 61800-3 and UL 508C standards. Lexium 62 ILM integrated servo modules can be controlled with all PacDrive LMC Eco and Pro/Pro 2 series motion controllers via SERCOS communication. Multiaxis integrated servo drives from 0.31kW to 1.91kW for automation solutions based on PacDrive 3. PartnerPLC sources new and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	PacDrive 3
Product or component type	Power supply
Component name	LXM62

Complementary

Supply circuit type	AC
[Us] rated supply voltage	380...480 V three phase (tolerance: - 10...10 %); 208...360 V three phase (tolerance: - 10...10 %); 208...270 V single phase (tolerance: - 10...10 %)
Supply frequency	50/60 Hz +/- 5 %
[Uc] control circuit voltage	24 V DC (tolerance: - 20...25 %)
Power supply output current	20 A
Bus voltage	270…700 V
Maximum DC bus voltage	860 V
Maximum cable capacity	1.36 mF
[In] rated current	10 A single phase AC; 10 A three phase AC
Peak current	20 kA single phase AC for 1 s; 20 kA three phase AC for 1 s
Nominal power	5.2 kW at 400 V three phase AC; 6.2 kW at 480 V three phase AC
Maximum power	10.4 kW at 400 V three phase AC; 12.5 kW at 480 V three phase AC
Holding time	15 min
Braking resistance	15 Ohm
Permanent braking power	400 W
Maximum braking power	46 kW
Output type	2 relays for volt-free contacts
Physical interface	SERCOS III
Marking	CE
Safety level	Can reach SIL 2 conforming to IEC 61508; Can reach PL d/category 3 conforming to ISO 13849-1
Overvoltage category	III conforming to IEC 61800-5-1
Depth	270 mm
Width	89.5 mm
Height	310 mm
Net weight	6.3 kg

Environment

Standards	UL 508C; IEC 61800-5-1; IEC 61800-3
Product certifications	UL; CSA
IP degree of protection	IP20 conforming to IEC 60721-3-3 (with plugged-in connectors)
Vibration resistance	10 m/s² conforming to IEC 60721-3-3
Shock resistance	100 m/s² in operation conforming to IEC 60721-3-3; 300 m/s² during transport conforming to IEC 60721-3-3
Pollution degree	2 conforming to IEC 60721-3-3
Environmental characteristic	3K3 conforming to IEC 60721-3-3 5…85 %
Ambient air temperature for operation	40…55 °C (with current derating of 2 % per °C); 5…40 °C
Ambient air temperature for storage	-25…55 °C
