Schneider Electric LXM62DD45A21000 – Lexium 62 Single Drive - accessory kit included

MPN: LXM62DD45A21000 · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original LXM62DD45A21000 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Lexium 62 & Motors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
UPC / EAN	3606485306049
Recommended replacement	LXM62DD45C21000
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the LXM62DD45A21000 now that it is discontinued?

Yes. Schneider Electric has discontinued the LXM62DD45A21000, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the LXM62DD45C21000 as its successor — we can quote both.

When can LXM62DD45A21000 be shipped?

LXM62DD45A21000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up LXM62DD45A21000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for LXM62DD45A21000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LXM62DD45A21000, subject to availability and destination.

Schneider Electric LXM62DD45A21000 — Lexium 62 Single Drive - accessory kit included. Discontinued by Schneider Electric; the manufacturer's successor is LXM62DD45C21000. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	PacDrive 3
Device short name	LXM 62
Product or component type	Single drive
Component name	LXM62

Complementary

Network number of phases	Three phase
[Us] rated supply voltage	400 V (- 10...10 %) for three phase; 230 V (- 10...10 %) for three phase; 230 V (- 10...10 %) for single phase
Supply frequency	50/60 Hz - 5...5 %
Continuous output current	20 A at 4 kHz
Output current 3s peak	45 A at 4 kHz
Switching frequency	8 kHz
Overvoltage category	III
Electrical connection	Terminal, clamping capacity: 0.2...15 mm², 24 AWG...16 AWG (CN4); Terminal, clamping capacity: 0.5...16 mm², 20 AWG...6 AWG (CN5); Terminal, clamping capacity: 0.75...16 mm², 18 AWG...6 AWG (CN6); Terminal, clamping capacity: 0.2...6 mm², 24 AWG...10 AWG (CN7)
Tightening torque	CN1: 2.5 N.m
Number of inputs	2 digital; 2 touch probe
Discrete input voltage	24 V DC for - 20...25 %
Number of outputs	2 digital
Discrete output voltage	24 V DC
Safety function	STO (safe torque off)
Communication interface	SERCOS III, integrated
Net weight	3 kg

Environment

Standards	IEC 62061; ISO 13849-1; IEC 61800-3; UL 508C; IEC 61800-5-1; IEC 61508; IEC 61800-5-2; ISO 13849-2; CSA C22.2 No 14
Product certifications	CE; CSA; UL; EAC; TÜV
IP degree of protection	IP20 conforming to IEC 60529
Vibration resistance	10 m/s² conforming to IEC 60721-3-3
Shock resistance	100 m/s² conforming to IEC 60721-3-3
Pollution degree	2 conforming to IEC 61800-5-2
Environmental characteristic	3K3 conforming to IEC 60721-3-3
Relative humidity	5…85 %
Ambient air temperature for operation	5…55 °C
