Schneider Electric BMXERT1604T
Multifunction input module, Modicon X80, 16 I, 24/24-125V DC
- MPN
- BMXERT1604T
- EAN
- 3595864146232
- Category
- Modicon X80 modules
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric BMXERT1604T?
This product is part of the Modicon X80 range, a common platform of modules for Modicon M580 and M340 Programmable Automation Controllers (PAC). This multifunction input module has 16 inputs with hot swap function. It has 4 groups of 4 input channels for process input with configurable from 0ms to 255ms anti bounce filtering. It is an module with a rated supply voltage of 24V DC, 48V DC to 60V DC, 110V DC to 125V DC and a current consumption of 30mA. Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs. It has 4 groups of 4 input channels for process input with configurable from 0ms to 255ms anti bounce filtering. Its dimensions are 32mm (width) x 86mm (depth) x 100mm (height). This product meets the needs of our customers from Smart Infrastructure, Water and Waste Water, Consumer Packaged Goods, Mining Minerals Metals, Data centers and Power generation. This product is certified by Merchant Navy, C-Tick and GOST. It meets EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs.
Specifications
Specifications
| Range of product | Modicon X80 |
| Product or component type | Multifunction input module |
| Function available | Hot swap |
| Data recording | 1 ms time stamps |
| Time synchronisation protocol | DCF77, IRIG-B |
| Group of channels | 4 groups of 4 inputs for process input |
| [Us] rated supply voltage | 24 V DC (voltage range: 19...30 V), 48...60 V DC (voltage range: 38...75 V), 110...125 V DC (voltage range: 88...156 V) |
| Switching voltage | 125 V at 1.3 mA for process input, 110 V at 1.3 mA for process input, 60 V at 2.5 mA for process input, 48 V at 2.5 mA for process input, 24 V at 6.7 mA for process input |
| Maximum power consumption in W | 4 W for process input |
| Current consumption | 30 mA at 24 V DC, 130 mA at 3.3 V DC |
| Isolation voltage | 2500 V DC for 60 s bus to discrete input, 1400 V DC for 60 s bus to IRIG/DCF, 2500 V DC for 60 s discrete input to IRIG/DCF |
| Anti bounce filtering | Configurable from 0 to 255 ms |
| Sampling duration | 0.5 ms |
| Acquisition time | 1 ms |
| Local signalling | 1 LED (green) for firmware and module run (RUN), 1 LED (green) for status of time code input (T), 1 LED (red) for module fault (ERR), 1 LED (red) for power supply interruption (I/O), 16 LEDs for input status (0...15) |
| Width | 32 mm |
| Height | 100 mm |
| Depth | 86 mm |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 4000 m |
| Directives | 2014/35/EU - low voltage directive, 2014/30/EU - electromagnetic compatibility |
| Product certifications | CE, RCM, CSA, EAC, Merchant Navy, UL |
| Standards | IEC 61010-2-201, IEC 61131-2, UL 61010-2-201, CSA C22.2 No 61010-2-201 |
| Environmental characteristic | Gas resistant class Gx, Gas resistant class 3C4, Dust resistant class 3S4, Sand resistant class 3S4, Salt resistant level 2, Mold growth resistant class 3B2, Fungal spore resistant class 3B2 |
Packaging
| Package 1 | 1 PCE, 11.700 cm × 11.000 cm × 5.500 cm (L × W × H), 150.000 g |
| Package 2 | 15 S02, 40.000 cm × 30.000 cm × 15.000 cm (L × W × H), 2.600 kg |
