Schneider Electric BGM2200-GR

APC Back-UPS Pro for Gaming, 2200VA/1320W, Tower, 230V, 4x Schuko and 2x IEC C13 outlets, RGB Lights, Pure Sine Wave, Arctic (White)

MPN
BGM2200-GR
EAN
0731304634775
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original BGM2200-GR (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric BGM2200-GR?

This APC Back-UPS Pro offers premium power protection for high performance gaming consoles and PC, routers/modems, and gaming accessories. The 2200VA/1320W tower UPS has 6 total outlets, 3 of which are battery back up and surge protection, and 3 that are surge protection only. It has a surge energy rating of 1080 Joules. It features Automatic Voltage Regulation to correct voltage dips and surges to proper levels. It comes with PowerChute Serial Shutdown, an easy-to-use safe system shutdown software with power and energy management features. This UPS has a 3-year warranty and a $150,000 connected equipment protection policy. It has 2 USB ports (Type A + C) for smart charging of personal devices.

Specifications

Specifications

Max. Capacity Used
Main Input Voltage230 V AC 1 phase
Input voltage230 V
Input Connection TypeSchuko
Maximum input current12 A
Input harmonic distortionLess than 3 % for full load
Input protection typeCircuit breaker
Switching current capacity15 A
Plug standardSchuko
Input voltage limits168...302 V
Network frequency50/60 Hz +/- 3 Hz
Output voltage230 V AC 1 phase
Rated power in W1320 W
rated power in VA2200 VA
Output connection type4 Schuko surge, 2 IEC 60320 C13
USB Charging PortUSB type A + C
Maximum configurable power in VA2200 VA
Maximum configurable power in W1320 W
Transfer time8 ms typical : 10 ms maximum
UPS typeLine interactive
Wave typeSine wave
Full load runtime00:30:00
Half load runtime00:04:19
Output frequency50/60 Hz +/- 3 Hz sync to mains
Battery typeLead-acid battery
Control panelMultifunction LCD status and control console
Free slots0
AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
UPS connectivityUSB port
Surge energy rate1080 J
Noise suppressionFull time multi-pole noise filtering : 5% of IEEE surge let-through : zero clamping response time: instantaneous
Cable length1.5 m
Number of cables1
ColourWhite
Height292.1 mm
Width104.14 mm
Depth408.94 mm
Net weight12.3 kg
Mounting supportFloor
Mounting preferenceNo preference
Mounting modeTower
Two post mountable0
USB compatibleYes
Mounting positionVertical
Number of power module free slots0
Number preinstalled power module0
Additional specificationGaming performance
RedundantNo
Range of productBack-UPS Pro
Product or component typeUninterruptible power supply (UPS)
Product certificationsCE, CB
Equipment protection policyLifetime : 50000 euros
Ambient air temperature for operation0…40 °C
Ambient air temperature for storage-15…40 °C
Storage altitude0…3048 m
IP degree of protectionIP20
Relative humidity0…95 %
Storage Relative Humidity0…95 %
Acoustic level45 dBA
Operating altitude0...10000 ft
Run TimeView Runtime Graph
EfficiencyView Efficiency Graph
Battery voltage24 V
Number of battery filled slots1
Number of battery free slots0
Battery recharge time16 h
Number of battery replacement quantity1
Overcurrent protection15 A
Battery life3…5 year(s)
Battery charger power12 W rated
SCC1420731304634779

Packaging

Package 11 PCE, 48 cm × 35.5 cm × 15.5 cm (L × W × H), 14.52 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

BGM2200-GR: frequently asked questions

Can I still buy the BGM2200-GR now that it is discontinued?

Yes. Schneider Electric has discontinued the BGM2200-GR, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can BGM2200-GR be shipped?

BGM2200-GR is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BGM2200-GR in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BGM2200-GR and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BGM2200-GR, subject to availability and destination.
