plug-in solid state relay - 5 mm - output - 24 V DC - 2 A
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon ABE7 |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 4 kg |
Shipping & availability
When can ABS7SC1B be shipped?
ABS7SC1B is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ABS7SC1B in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ABS7SC1B and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ABS7SC1B, subject to availability and destination.
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This is a plug-in solid state relay for output sub-bases. This is a 5mm wide output relay. This product allows AC or DC electrical current to be switched without mechanical movement. It is a solid sate relay with 24Vcc nominal voltage and 2A current. Its response time is lower or equal to 0.01ms from state 0 to 1, and lower or equal to 0.4ms from state 1 to 0. It weighs 0.010kg. It is suitable for Optimum and Universal output sub-bases. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.
Specifications
Specifications
| Response time | <= 0.01 ms from state 0 to 1, <= 0.4 ms from state 1 to 0 |
| Product compatibility | ABE7R16T111, ABE7P16M111, ABE7P16T111 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 0.5 cm |
| Package 1 Width | 1.8 cm |
| Package 1 Length | 2.8 cm |
| Package 1 Weight | 4.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 4 |
| Package 2 Height | 0.7 cm |
| Package 2 Width | 2.4 cm |
| Package 2 Length | 15.1 cm |
| Package 2 Weight | 23 g |
| Unit Type of Package 3 | S01 |
| Number of Units in Package 3 | 100 |
| Package 3 Height | 15 cm |
| Package 3 Width | 15 cm |
| Package 3 Length | 40 cm |
| Package 3 Weight | 773 g |
| Warranty (in months) | 18 |
