Schneider Electric 140SDO95300S

Safety dc discrete output module - 16 outputs - 19.2..30 V DC

MPN
140SDO95300S
EAN
3595863953565
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 140SDO95300S (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 140SDO95300S?

Schneider Electric 140SDO95300S — safety dc discrete output module - 16 outputs - 19.2..30 V DC (Modicon Quantum). Discontinued by Schneider Electric; the manufacturer's successor is BMXSDO0802. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Quantum automation platform
Product or component typeSafety dc discrete output module

Complementary

Discrete output number16
Group of channels1
Discrete output logicPositive logic (source)
Addressing requirement4 output words; 7 input words
Discrete output voltage19.2...30 V DC
Absolute maximum output34 V
Maximum voltage drop<0.3 V 0.5 A
Sensor power supply19.2…30 V
Maximum load current<= 0.65 A each point; <= 10.04 A each group
Surge current2 A for 10 ms
Response time<= 20 ms at state 0 to state 1; <= 20 ms at state 1 to state 0
Maximum leakage current0.5 mA 30 V
Protection typeWith
Load inductanceInductance(H) = 0.5/((current(A))² x (switching frequency(Hz))); 0.5 8 Hz
Fault indicationChannel fault; Overload; Power supply fault; System fault
Associated fuse rating10 A
Isolation between channels and bus1500 Vrms for 1 minute
Isolation between group and bus1500 Vrms for 1 minute
Power dissipation1.9 W + 0.65 I²
MarkingCE
Local signalling1 LED (green) for bus communication is present (Active); 1 LED (red) for external fault detected (F); 16 LEDs (green) for output status; 16 LEDs (red) for system failure, diagnostic of internal channel fault
Bus current requirement350 mA

Environment

Product certificationsTÜV Rheinland (SIL2); CSA; CSA HazLoc; UL; C-Tick

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

140SDO95300S: frequently asked questions

Can I still buy the 140SDO95300S now that it is discontinued?

Yes. Schneider Electric has discontinued the 140SDO95300S, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXSDO0802 as its successor — we can quote both.

When can 140SDO95300S be shipped?

140SDO95300S is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140SDO95300S in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140SDO95300S and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140SDO95300S, subject to availability and destination.
