Pilz 535111
PSEN ix2 F4 code
- MPN
- 535111
- EAN
- 4046548083422
- Category
- Wiring guides
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Pilz 535111?
PSEN, decentralised passive junction for series connection, connectionup to 4 safety sensors (series-connectable), max. 5 PSEN ix2 F4 code with max. 16 subscribers, forwarding of diagnostic information, 96 x 48 x 57 mm (H x W x D), connection type spring-loaded terminals, IP20.
Specifications
General data
| Product ID (Pilz order number) | 535111 |
| Approval | CE, UL/cUL |
| Lifecycle | Active (current Pilz product) |
Electrical data
| Type of rated voltage U1 | DC |
Environmental data
| Ambient temperature | -10 … 55 °C |
Mechanical data
| Connection terminal | Spring-loaded terminal |
| Height dimension | 57 mm |
| Width dimension | 96 mm |
| Depth dimension | 48 mm |
| Net weight | 112 g |
| Gross weight | 122 g |
Environment
| RoHS directive | 2011/65/EU, 2015/863/EU |
| RoHS conformity | yes |
| RoHS exceptions | no |
| REACh compliance | Contains no SVHC substances |
| WEEE classification (08/2018) | 5 devices (feed size < 50cm) |
Commercial data
| ECLASS version | ECLASS-13 |
| ECLASS Reference Feature | 27440111 |
| ETIM Version | ETIM-9.0 |
| ETIM Reference Group | EG000026 |
| ETIM Reference Feature | EC002594 |
| UNSPSC 25 | 39122205 |
| GTIN | 4046548083422 |
| Volume | 0 dm3 |
| Harmonized System Code | 85389099 |
| Quantity per packaging unit | 1 |
Downloads & documentation
Official documents from Pilz, downloaded directly from the manufacturer.
Data sheets & manuals
CAD & dimension drawings
535111: frequently asked questions
When can 535111 be shipped?
535111 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 535111 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 535111 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 535111, subject to availability and destination.
