S-N48 Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN: S-N48 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Magnetic Contactors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can S-N48 be shipped?

S-N48 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up S-N48 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for S-N48 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for S-N48, subject to availability and destination.

The Mitsubishi Electric S-N48 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 50A (Category AC-3 AC200V) AC Operated. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	Representative rating 50A (Category AC-3 AC200V) AC Operated

Specifications

Product Specification	AC Operated
Rated Insulation Voltage Ui [V]	690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	11
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V	15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V	18.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V	18.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V	15
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V	27
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V	55
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V	8
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V	16
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	35
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	24
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V	50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V	40
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V	32
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V	17
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V	80
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V	80
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V	80
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V	80
Main Contact Conventional Free Air Thermal Current [A]	80
Main Contact Minimal Applicable Load	48V 200mA
Contact Arrangements (Valid): Main Contact (Standard)	3NO
Main Contact Making Current Capacity [A]: Category AC-3: AC220V	500
Main Contact Making Current Capacity [A]: Category AC-3: AC440V	400
Main Contact Making Current Capacity [A]: Category AC-3: AC550V	320
Main Contact Making Current Capacity [A]: Category AC-3: AC690V	170
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V	400
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V	320
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V	256
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V	136
Mechanical Durability [Mil.Times]	500
Electrical Durability [Mil.Times]: Category AC-3 (Japan)	100
Electrical Durability [Mil.Times]: Category AC-1	50
Switching Frequency [Times/Hour]: Category AC-3	1200
Operation Coil Properties: Operating Voltage	AC Operated
Operation Coil Properties: Inrush Input [VA]	110
Operation Coil Properties: Normal input [VA]	13
Operation Coil Properties: Power Consumption [W]	4.3
Functions: Coil Surge Absorbing Function	No
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting,DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)	M5
Terminal Screw Size: Main Circuit (Load Side)	M5
Terminal Screw Size: Operation Coil	M3.5
