Mitsubishi Electric S-N48SA

Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN
S-N48SA
Price and lead time confirmed within 1 business day

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original S-N48SA (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric S-N48SA?

The Mitsubishi Electric S-N48SA is a magnetic Contactor in the Low-voltage switchgear. Representative rating 50A (Category AC-3 AC200V) AC Operated. Mitsubishi Electric has discontinued it (2023/04 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Sales status2023/04 Discontinued (Mitsubishi Electric)
OutlineRepresentative rating 50A (Category AC-3 AC200V) AC Operated

Specifications

Product SpecificationAC Operated
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V11
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V18.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V18.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V15
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V27
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V55
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V8
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V16
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V35
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V24
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V40
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V32
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V17
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V80
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V80
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V80
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V80
Main Contact Conventional Free Air Thermal Current [A]80
Main Contact Minimal Applicable Load48V 200mA
Contact Arrangements (Valid): Main Contact (Standard)3NO
Main Contact Making Current Capacity [A]: Category AC-3: AC220V500
Main Contact Making Current Capacity [A]: Category AC-3: AC440V400
Main Contact Making Current Capacity [A]: Category AC-3: AC550V320
Main Contact Making Current Capacity [A]: Category AC-3: AC690V170
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V400
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V320
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V256
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V136
Mechanical Durability [Mil.Times]500
Electrical Durability [Mil.Times]: Category AC-3 (Japan)100
Electrical Durability [Mil.Times]: Category AC-150
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]110
Operation Coil Properties: Normal input [VA]13
Operation Coil Properties: Power Consumption [W]4.3
Functions: Coil Surge Absorbing FunctionYes
Functions: Terminal CoversNo
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)M5
Terminal Screw Size: Main Circuit (Load Side)M5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

S-N48SA: frequently asked questions

Can I still buy the S-N48SA now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the S-N48SA, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can S-N48SA be shipped?

S-N48SA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up S-N48SA in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for S-N48SA and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for S-N48SA, subject to availability and destination.
