What is the Mitsubishi Electric QE8WH4VT?

The Mitsubishi Electric QE8WH4VT is a energy measuring in the MELSEC-Q Series. Voltage converter for energy measuring module (Necessary for voltage input of QE81WH4W and QE83WH4W.). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSEC-Q Series
CategoryEnergy measuring
TypeVoltage transform module
OutlineVoltage converter for energy measuring module (Necessary for voltage input of QE81WH4W and QE83WH4W.)

Specifications

Phase wire system3-phase 4-wire
Input voltage range63.5/110 to 277/480VAC (Does not operate below 55/95VAC.)
Frequency50/60Hz
Tolerable voltage output error±1.0% (in respect to rated primary voltage)
Max. No. of connected units5 units
VA consumptionP1-P0 : 2VA, P2-P0 : 0.3VA, P3-P0 : 0.3VA (at 277/480VAC input)
Current consumption30mA
Secondary wiring lengthMax. 5m
Mounting methodIEC rail mounting, screw tightening
Weight0.3kg

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

QE8WH4VT: frequently asked questions

When can QE8WH4VT be shipped?

QE8WH4VT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up QE8WH4VT in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for QE8WH4VT and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for QE8WH4VT, subject to availability and destination.
