What is the Mitsubishi Electric QE81WH4W?

The Mitsubishi Electric QE81WH4W is a energy measuring in the MELSEC-Q Series. Number of measurement circuits : 1 circuit Phase wire system : 3-phase 4-wire Measurement items : Current, demanded current, voltage, power, demanded power, reactive power, apparent power, frequency, power factor, electric energy, reactive electric energy, time-based electric energy. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSEC-Q Series
CategoryEnergy measuring
OutlineNumber of measurement circuits : 1 circuit Phase wire system : 3-phase 4-wire Measurement items : Current, demanded current, voltage, power, demanded power, reactive power, apparent power, frequency, power factor, electric energy, reactive electric energy, time-based electric energy

Specifications

Number of measurement circuits1 circuit (1 channel)
Phase wire systemThree-phase 4-wire
Instrument rating: Voltage circuit: 3-phase 4-wire63.5/110 to 277/480V AC (When the voltage exceeds 277/480V AC, a voltage transformer is required. The primary voltage values of the voltage converter (QE8WH4VT) are shown.)
Instrument rating: Current circuit50A, 100A, 250A, 400A, 600A (Dedicated split-type current sensor is used. All values indicate primary current values of current sensor.) 5A (Dedicated 5A current sensor is used. Current transformer (CT) is used in two-step configuration together with the 5A current sensor in order to allow a maximum primary current value setting of 6,000A)
Instrument rating: Frequency50 to 60Hz (automatic frequency selection)
Main unit tolerances (current sensors not included in tolerance)Current, demanded current : ±1.0% (relative to rated input) Voltage : ±1.0% (relative to rated input) Power, demanded power : ±1.0% (relative to rated input) Reactive power : ±1.0% (relative to rated input) Apparent power : ±1.0% (relative to rated input) Frequency : ±1.0% (in 45 to 65Hz range) Power factor : ±3.0% (relative to electrical angle of 90°) Electric energy : ±2.0% (in 5 to 100% range o
Data update cycle250ms
Response time2s or less
Power outage compensationBackup is made using nonvolatile memory. (Stored items: settings, the max./min. values and time of occurrence, electric energy (consumption, regenerated), reactive energy (consumption lag), and periodic electric energy)
Internal current cunsumption (DC 5V)0.18A
No. of required slots1
No. of input/output points16 points (I/O assignment: 16 intelligent points)
Applicable wire: Voltage input terminal: Single wireAWG24 to AWG16
Applicable wire: Voltage input terminal: Stranded wireAWG24 to AWG16
Applicable wire: Current input terminal: Single wireAWG26 to AWG16
Applicable wire: Current input terminal: Stranded wireAWG26 to AWG18
Applicable standardsEMC: EN61131-2:2007, EN61326-1:2013 LVD: EN61131-2:2007, EN61010-1:2010 UL Standards: UL508 c-UL Standards: CSA C22.2 No.142 KC Marking
External dimensions: Height (H)98mm
External dimensions: Width (W)27.4mm
External dimensions: Depth (D)90.5mm
Weight0.10kg

Specifications

General SpecificationsRefer to the general Specifications of CPU module.
