MXF100-16-N32-EC Mitsubishi MELSEC MX Controller

MPN: MXF100-16-N32-EC · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC MX Controller – Controller
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can MXF100-16-N32-EC be shipped?

MXF100-16-N32-EC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up MXF100-16-N32-EC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for MXF100-16-N32-EC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MXF100-16-N32-EC, subject to availability and destination.

The Mitsubishi Electric MXF100-16-N32-EC is a controller in the MELSEC MX Controller. Program memory: 30 MB Maximum number of controllable axes: 16 axes Built-in EtherCAT Input: 16 points Output: 16 points transistor (sink). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC MX Controller
Outline	Program memory: 30 MB Maximum number of controllable axes: 16 axes Built-in EtherCAT Input: 16 points Output: 16 points transistor (sink)

Specifications

Operation control method	Repetitive operation of stored programs
I/O control mode	Refresh mode (The direct access input/output is available by specifying the direct access input/output (DX, DY).)
Programming language	• Ladder diagram (LD) • Structured text (ST) • Function block diagram (FBD/LD)
Extended programming language	• Function block (FB) • Label programming
Program execution type	Initial, scan, fixed scan, interrupt, and standby
Number of I/O points	512 points
Memory capacity: Program memory	30 MB
Memory capacity: Program cache memory	12 MB
Memory capacity: Device/label memory	8 MB
Memory capacity: Data memory	15 MB
Online change	Supported
Processing speed: Double-precision floating-point processing	2.50 ns…
Processing speed: Instruction processing time: LD instruction	1.25 ns…
Number of occupied I/O points	Not supported
Number of slots occupied by a module	Not supported

Peripheral connection port

USB port	USB 2.0 High Speed (Type-C) × 1
Ethernet port	1000BASE-T/100BASE-TX × 1
EtherCAT port	100BASE-TX × 1

Memory interface

SD memory card

SD/SDHC memory card

Motion control specifications

Number of controllable axes: Real drive axis	16 axes
Motion operation cycle [μs]	250, 500, 1000, 2000, 4000, 8000
Servo amplifier connection	MR-J5-G-N1, MR-J5D1-G4-N1, EtherCAT-compatible drive Multi-axis drive unit operation including MR-J5W2-G-N1 and MR-J5W3-G-N1 will be supported in the future.
Absolute position control system	64 bit control/32 bit control
Positioning range	64 bit floating-point (LREAL type)
Interpolation function	Linear interpolation (4 axes maximum), 2-axis circular interpolation
Control method	PTP control, speed control, speed-position switching control (future support), multi-axis positioning data operation, position follow-up control, and motion cyclic instruction (position, velocity, and torque)
Operation cycles mixed	1 group
System memory size	96 MB
Size of built-in ROM for user data	15 MB (Data memory is used.)
Axis	Real drive axis, virtual drive axis, real encoder axis, virtual encoder axis, and virtual linked axis
Axis: Axes group	0: Not set 1…: Setting axes group No.
Axis: Real drive axis	Servo amplifier
Axis: Real encoder axis	Via a servo amplifier
Compensation function	Driver unit conversion function and phase compensation function (future support)
Synchronous control: Instruction	Advanced synchronous control and cam operation start (MC_Camln)
Synchronous control: Module	Master axis, cam, gear, and clutch
Synchronous control: Master axis	Real drive axis, virtual drive axis, real encoder axis, virtual encoder axis, and virtual linked axis
Start/stop	Start, stop, restart, buffer mode, and forced stop
Home position return: Home position return method	Driver home position return method (use the home position return method set in the driver)
Positional control: Linear control	Linear interpolation (2…4 axes)
Positional control: 2-axis circular interpolation	Border point specification, center point specification, and radius specification
Manual control	JOG operation
Direct control: Speed control	Speed control not including position loop and speed control including position loop
Direct control: Torque control	Torque control
Absolute positioning system	Provided (batteryless)
Function to limit control: Velocity limit	Velocity set range
Function to limit control: Torque limit	Positive direction torque limit value, negative direction torque limit value
Function to limit control: Forced stop	Enabled/disabled switching
Function to limit control: Software stroke limit	Check the movable range at the set position and the machine feed value.
Function to limit control: Hardware stroke limit	Supported
Function to change control content: Set velocity change	Supported
Function to change control content: Current value change	Supported
Function to change control content: Acceleration/deceleration process change	Acceleration/deceleration and acceleration/deceleration time
Function to change control content: Torque limit value change	Supported
Function to change control content: Target position change	Target position change and movement distance change
Function to change control content: Override	Supported
Function: History data	Position data history
Function: Axis emulation	Supported
Function: Touch probe (mark detection)	Supported
Function: Monitoring of servo data	SDO communication and PDO communication
Function: Servo system recorder	Not supported
Function: Digital cam switch	Not supported

Operation profile data (cam) specifications

Number of registrations	60000 maximum (settable number from engineering tool: 1024)
Cam data: Type	Cam data and rotary knife
Cam data: Interpolation method	Specifying for each section, linear interpolation, and spline interpolation
Cam data: Profile ID	1…60000
Cam data: Resolution	8…65535 (optional)
Cam data: Unit of length per cycle setting	mm, inch, pulse, degree
Cam data: Unit of stroke amount	%, mm, inch, pulse, degree
Cam auto-generation	Cam auto-generation cam for rotary knife

Network (EtherCAT) specifications

EtherCAT communication specifications	CAN application protocol over EtherCAT (CoE)
Type	MainDevice
Transmission speed	100 Mbps
Maximum number of connectable stations per network	73 stations (MainDevice: 1, SubDevice: 72) *1
Network topology	Line topology, star topology
Overall cable length: Line topology	7200 m (when 73 stations are connected)
Overall cable length: Others	Depends on the system configuration.
Maximum station-to-station distance	100 m
PDO (process data communication): Maximum number of link points per network: Input	8192 points (8192 words)
PDO (process data communication): Maximum number of link points per network: Output	8192 points (8192 words)
PDO (process data communication): Maximum number of link points per station: Input	8192 points (8192 words)
PDO (process data communication): Maximum number of link points per station: Output	8192 points (8192 words)
SDO (mailbox communication): Size: Input	400 words
SDO (mailbox communication): Size: Output	400 words
SDO (mailbox communication): Function	SDO Upload, SDO Download
Communication method	Full-duplex

Power supply specifications

Rated voltage	24 V DC
Voltage fluctuation range	+20%, -15%
Allowable momentary power failure time	5 ms or less (at 24 V)
Power fuse	125 V, 3.15 A time-lag fuse
Inrush current	100 A, 0.06 ms or less 4.0 A, 350 ms or less
Power consumption	Controller alone: 13.6 W or less Maximum configuration for connection to the controller: 32.0 W or less (external 24 V DC power supply of extension devices is not included)
24 V DC built-in power supply capacity	500 mA
5 V DC built-in power supply capacity	720 mA

Specifications

Operating ambient temperature *2	0…55°C, non-freezing
Storage ambient temperature	-25…75°C, non-freezing
Operating ambient humidity	5…95% RH, non-condensing *3
Storage ambient humidity	5…95% RH, non-condensing
Vibration resistance 4 5: Installed on DIN rail: Frequency: 5…8.4 Hz	Half amplitude: 1.75 mm Number of sweeps: 10 times each in X, Y, and Z directions (total 80 minutes in each direction)
Vibration resistance 4 5: Installed on DIN rail: Frequency: 8.4…150 Hz	Constant acceleration: 4.9 m/s 2 Number of sweeps: 10 times each in X, Y, and Z directions (total 80 minutes in each direction)
Shock resistance *4	147 m/s 2 , Duration of action: 11 ms, 3 times each in X, Y, and Z bidirections by sine half-wave pulse
Noise immunity	By noise simulator at noise voltage of 1000 Vp-p, noise width of 1 μs and period of 30…100 Hz
Grounding	Grounding resistance of 100Ω or less (Common grounding with a heavy electrical system is not allowed) *6
Operating atmosphere	No corrosive gases and flammable gases, less conductive dust
Operating altitude *7	0…2000 m
Installation location	Inside a control panel *8
Overvoltage category *9	II or less
Pollution degree *10	2 or less
