HK-ST1724WBWS Mitsubishi MELSERVO servo MELSERVO-J5 series

MPN: HK-ST1724WBWS · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSERVO servo – Rotary servo motors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can HK-ST1724WBWS be shipped?

HK-ST1724WBWS is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up HK-ST1724WBWS in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for HK-ST1724WBWS and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for HK-ST1724WBWS, subject to availability and destination.

The Mitsubishi Electric HK-ST1724WBWS is a MELSERVO-J5 series in the MELSERVO servo. 200 V: 1000 400 V: 2000. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSERVO servo
Category	MELSERVO-J5 series
Type	200 V AC 400 V AC
Outline	200 V: 1000 400 V: 2000

Specifications

Series	MELSERVO-J5 series
Power class	200 V AC 400 V AC
Model name	HK-ST1724WBWS
Compatible servo amplifier *1	Refer to " Combinations of Rotary Servo Motors and Servo Amplifiers ".
Power supply capacity [kVA]	Refer to "Power Supply Capacity" for the power supply capacity in "MELSERVO-J5 catalog".
Continuous running duty *5: Rated output [kW]	200 V: 0.85 400 V: 1.75
Continuous running duty 5: Rated torque [N・m] 4 *6	200 V: 8.1 400 V: 8.4
Maximum torque [N・m] *4	200 V: 24.4 400 V: 25.1
Rated speed [r/min] 4 5	200 V: 1000 400 V: 2000
Maximum speed [r/min] *5	200 V: 2000 400 V: 4000
Power rate at continuous rated torque [kW/s] *4	200 V: 48.3 400 V: 51.1
Rated current [A] *4	200 V: 4.5 400 V: 4.7
Maximum current [A] *4	200 V: 17 400 V: 16
Moment of inertia J [x 10 -4 kg・m 2 ]	13.7
Recommended load to motor inertia ratio *2	200 V: 24 times or less 400 V: 4 times or less *9 (When connected with MR-J5D, 11 times or less)
Speed・position detector	Batteryless absolute/incremental 26-bit encoder (resolution: 67,108,864 pulses/rev)
Type	Permanent magnet synchronous motor
Oil seal	None (Servo motors with an oil seal are available.)
Thermistor	None
Insulation class	155 (F)
Structure	Totally enclosed, natural cooling (IP rating: IP67) *3
Environment: Ambient temperature: Operation	0 °C to 60 °C (non-freezing) *20
Environment: Ambient temperature: Strage	-15 °C to 70 °C (non-freezing)
Environment: Ambient humidity: Operation	10 %RH to 90 %RH (non-condensing)
Environment: Ambient humidity: Strage	10 %RH to 90 %RH (non-condensing)
Environment: Ambience *19	Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist or dust, no object generating a strong magnetic field
Environment: Altitude	2000 m or less *21
Environment: External magnetic field	10 mT or less
Environment: Vibration resistance *50	X: 24.5 m/s 2 ,Y: 49 m/s 2
Vibration rank	V10 *50
Satisfied standards	Refer to " Standards and certifications (by product) Products " for compliance with global standards and regulations.
Permissible load for the shaft *50: L [mm]	55
Permissible load for the shaft *50: Radial [N]	980
Permissible load for the shaft *50: Thrust [N]	490
Mass [kg]	8.8

Specifications

Electromagnetic Brake *22: Servo motor model name	HK-ST1724WBWS
Electromagnetic Brake *22: Type	Spring actuated type safety brake
Electromagnetic Brake *22: Rated voltage	24 V DC (-10 % to 0 %)
Electromagnetic Brake *22: Power consumption [W] at 20 ﾟC	20
Electromagnetic Brake *22: Electromagnetic brake static friction torque [N・m]	8.5 or higher
Electromagnetic Brake *22: Permissible braking work: Per braking [J]	400
Electromagnetic Brake *22: Permissible braking work: Per hour [J]	4000
Electromagnetic Brake 22: Electromagnetic brake life 23: Number of braking times	20000
Electromagnetic Brake 22: Electromagnetic brake life 23: Work per braking [J]	200
