Mitsubishi Electric GT27-MMR-Z
Mitsubishi GOT HMI Option unit
- MPN
- GT27-MMR-Z
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric GT27-MMR-Z?
The Mitsubishi Electric GT27-MMR-Z is a option unit in the GOT HMI. For video input (NTSC/PAL), 1 channel recording video/playing video files. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | For video input (NTSC/PAL), 1 channel recording video/playing video files |
Specifications
| Model | GT27-MMR-Z |
| Category | Option units |
| Product name | Multimedia unit |
| Series name | GOT2000 |
| Video input section: Video input format: Color | NTSC format, PAL format (interlaced format) |
| Video input section: Video input format: Monochrome | EIA format, CCIR format (interlaced format) |
| Video input section: Number of channels | 1 channel |
| Video input section: Video input signal | 1 Vp-p, 75Ω, composite signal |
| Video input section: Display size | 640 x 480 dot, 768 x 576 dot *1 |
| Video input section: Connector for external connection | BNC connector |
| Sound input section: Number of channels | 1 channel |
| Sound input section: Sound input signal | 1 Vrms |
| Sound input section: Connector for external connection | φ3.5 stereo mini jack, straight type |
| Sound output section: Number of channels | 1 channel |
| Sound output section: Sound output signal | 1 Vrms (Rated load 10 kΩ) |
| Sound output section: Connector for external connection | φ3.5 stereo mini jack, straight type |
| CF Card I/F section: Slot | Compact flash Slot (TYPE1) 1 channel |
| CF Card I/F section: Mode | True-IDE mode |
| Ethernet I/F section: Number of channels | 1 channel |
| Ethernet I/F section: Connector for external connection | RJ45 (modular jack) |
| Ethernet I/F section: Data transfer method | 100BASE-TX/10BASE-T |
| Video file: File format | 3GP, MP4 |
| Video file: Video coding/decoding format | MPEG-4 Part.2 SP@LV4 |
| Video file: Resolution/maximum frame rate | VGA/15fps, QVGA/30fps |
| Internal current consumption: 3.3 V DC | 0.51 A |
| Internal current consumption: 5.0 V DC | 0.49 A accompanied with the GT27-IF1000 |
| Weight | 0.41 kg accompanied with the GT27-IF1000 |
| Supported model | GT27 (Excluding GT2705-VTBD.) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- GOT2000 Series Multimedia Unit User's Manual (IB-0800518E-H)
- GOT2000系列 主机使用说明书(硬件篇) (SH-081202CHN-AW)
- GOT2000 Series Connection Manual (Microcomputers, MODBUS/Fieldbus Products, Peripherals) For GT Works3 Version1 (SH-081200ENG-AS)
- GOT2000系列 连接手册(微型计算机/MODBUS/现场总线/周边机器连接篇) 对应GT Works3 Version1 (SH-081208CHN-AS)
GT27-MMR-Z: frequently asked questions
When can GT27-MMR-Z be shipped?
GT27-MMR-Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT27-MMR-Z in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT27-MMR-Z and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT27-MMR-Z, subject to availability and destination.
