FX2N-1HC Mitsubishi MELSEC-F (FX) Series High-speed counter

MPN: FX2N-1HC · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original FX2N-1HC (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC-F (FX) Series – High-Speed Counter
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the FX2N-1HC now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the FX2N-1HC, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can FX2N-1HC be shipped?

FX2N-1HC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FX2N-1HC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FX2N-1HC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FX2N-1HC, subject to availability and destination.

The Mitsubishi Electric FX2N-1HC is a high-speed counter in the MELSEC-F (FX) Series. High-speed counter: 1 ch. Mitsubishi Electric has discontinued it (2020/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC-F (FX) Series
Category	High-speed counter
Sales status	2020/03 Discontinued (Mitsubishi Electric)
Outline	High-speed counter: 1 ch

Specifications

Applicable PLC	FX2N, FX3U, FX2NC, FX3UC [Connecting to the connector-type PLC] The FX2NC-CNV-IF is required to connect the FX2NC. The FX2NC-CNV-IF or FX3UC-1PS-5V is required to connect the FX3UC.
Number of occupied I/O points	8 point (Count either the input or output points of the PLC.)
Mass (weight)	0.3 kg
Range	When 32-bit is specified: -2,147,483,648 to +2,147,483,647 When 16-bit is specified: 0 to 65,535 (upper limit can be user specified)
Counter mode	Automatic UP/DOWN (however, when on 1-phase 1-input mode, UP/DOWN is determined by a PLC command or an input terminal.)
LED	φA, φB, DIS, PRE, YH, YS, POWER, UP, DOWN
No. of input channels	1 ch
Input type	Open collector, differential line driver (The differential line driver output type encoder is connected to 5 V terminal.)
Input voltage	5 V DC, 12 V DC, or 24 V DC can be selected with the connection terminal.
Max. response frequency: 1-phase 1-input	50 kHz or less
Max. response frequency: 1-phase 2-input	50 kHz or less
Max. response frequency: 2-phase input	50 kHz or less (1 edge count), 25 kHz or less (2 edge count), 12.5 kHz or less (4 edge count)
Match output (comparison)	Each output is set when the present value of the counter matches with the compare value (which is transferred from the PLC), and is switched OFF by a reset command from the PLC. YH: Direct output processed by hardware. YS: Software processed output with worst delay time of 300 μs. (When the input frequency is 50 kHz, there is a worst case delay of 15 input pulses.)
Output type	Open collector output 2 points 5 V to 24 V DC, 0.5 A

Power supply specifications

Power supply

5 V DC 90 mA (internal power supply from PLC main unit)

Specifications

Ambient temperature	0 to 55°C (32 to 131 °F) when operating and -25 to 75°C (-13 to 167 °F) when stored
Ambient humidity	5 to 95%RH (no condensation) when operating
Vibration resistance: Installed on DIN rail: Frequency: 10 to 57 Hz	Half amplitude: 0.035 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: Installed on DIN rail: Frequency: 57 to 150 Hz	Acceleration: 4.9 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: Direct installing: Frequency: 10 to 57 Hz	Half amplitude: 0.075 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: Direct installing: Frequency: 57 to 150 Hz	Acceleration: 9.8 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Shock resistance	147 m/s 2 Acceleration, Action time: 11 ms, 3 times by half-sine pulse in each direction X, Y, and Z
Noise resistance	By noise simulator at noise voltage of 1,000 Vp-p, noise width of 1 μs, rise time of 1 ns and period of 30 to 100 Hz
Dielectric withstand voltage	Between batch of all terminals and ground terminal of PLC main unit: 500 V AC for 1 min
Insulation resistance	Between batch of all terminals and ground terminal of PLC main unit: 5 MΩ or higher by 500 V DC insulation resistance tester
Working atmosphere	Free from corrosive or flammable gas and excessive conductive dusts
Working altitude	2000 m or less Do not use the PLC under pressure higher than the atmospheric pressure. Doing so may damage the PLC.
