Mitsubishi Electric CR800-02VD
Mitsubishi MELFA robot CR800-D
- MPN
- CR800-02VD
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric CR800-02VD?
The Mitsubishi Electric CR800-02VD is a CR800-D in the MELFA robot. Standalone type. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | MELFA robot |
| Category | CR800-D |
| Outline | Standalone type |
Specifications
| Category | Robot Controller |
| Series | CR800-D |
| Type | CR800-02VD |
| Applicable robot arm | RV-2FR/2FRL-D |
| Robot CPU | Built into controller |
| Path control method | PTP control and CP control |
| Number of axes controlled | Simultaneously 6 axes + additional 8 axes available |
| Robot language | MELFA-BASIC V, VI |
| Position teaching method | Teaching method, MDI method |
| Memory capacity: Number of teaching points: points | 39,000 |
| Memory capacity: Number of steps: step | 78,000 |
| Memory capacity: Number of programs: unit | 512 |
| External input/ output: General-purpose I/O: points | 0 input/0 output (Up to 256/256 when options are used) |
| External input/ output: Dedicated I/O: points | Assigned to general-purpose I/O |
| External input/ output: Special stop input: points | - |
| External input/ output: Gripper open/close: points | 4 input / 4 output |
| External input/ output: Emergency stop input: points | 1 (redundant) (*1) |
| External input/ output: Door switch input: points | 1 (redundant) |
| External input/ output: Enabling device input: points | - |
| External input/ output: Mode selector switch input: points | 1 (redundant) (*2) |
| External input/ output: Emergency stop output: points | 1 (redundant) |
| External input/ output: Mode output: points | 1 (redundant) |
| External input/ output: Robot error output: points | 1 (redundant) |
| External input/ output: Synchronization of additional axes: points | 1 (redundant) |
| External input/ output: Encoder input: channels | 2 |
| Interface: RS-232C: ports | - |
| Interface: RS-232: ports | - |
| Interface: RS-422: ports | 1 (dedicated T/B) |
| Interface: Ethernet: ports | 1 (dedicated T/B) 1 (for customer) 10BASE-T/100BASE-TX/1000BASE-T Correspondence with CC-Link IE Field Basic (Ver.A1d or later) |
| Interface: USB: ports | 1 (Ver. 2.0 device functions only, mini B terminal) (*3) |
| Interface: Hand dedicated slot: slots | - |
| Interface: Key switch interface: points | - |
| Interface: Additional axis, force sensor interface: channels | 1 (SSCNET III/H) |
| Interface: Tracking interface: channels | - |
| Interface: Memory slot: slots | - |
| Interface: Extension slot: slots | - |
| Interface: Option slot: slots | 2 |
| Interface: R/C communication interface: channels | 2 (daisy chain) |
| Interface: Remote I/O: channels | 1 (Ver.2.0) |
| Interface: Memory extension slot: slots | 1 |
| Ambient temperature: ˚C | 0 to 40 |
| Relative humidity: %RH | 45 to 85 |
| Power supply: Input voltage range: V | Single-phase AC 200V to 230V (*4) |
| Power supply: Power capacity: KVA | 0.5 (*5) |
| External dimensions (including legs): mm | 430(W)×425(D)×99.5(H) |
| Weight: kg | Approx. 12.5 |
| Structure [protective specification] | Self-contained floor type/open structure (Vertical and horizontal position can be placed) [IP20] (*6) |
| Grounding: Ω | 100 or less (class D grounding) (*7) |
| Control Type | Standalone type |
