A80BD-J61BT13 Mitsubishi MELSEC network modules Network interface boards
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original A80BD-J61BT13 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi MELSEC network modules – CC-Link |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
Can I still buy the A80BD-J61BT13 now that it is discontinued?
Yes. Mitsubishi Electric (Factory Automation) has discontinued the A80BD-J61BT13, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can A80BD-J61BT13 be shipped?
A80BD-J61BT13 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up A80BD-J61BT13 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for A80BD-J61BT13 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for A80BD-J61BT13, subject to availability and destination.
The Mitsubishi Electric A80BD-J61BT13 is a network interface boards in the MELSEC network modules. CC-Link local station PCI bus, Japanese/English OS supported. Mitsubishi Electric has discontinued it (2006/06 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | MELSEC network modules |
| Category | Network interface boards |
| Type | Local station |
| Subtype | Ver.1 compatible |
| Sales status | 2006/06 Discontinued (Mitsubishi Electric) |
| Outline | CC-Link local station PCI bus, Japanese/English OS supported |
Specifications
| Transmission speed | 156 kbps/625 kbps/2.5 Mbps/5 Mbps/10 Mbps (selectable) |
| Maximum overall cable distance (Maximum transmission distance): Ver. 1.10: 156 kbps | 1200 m |
| Maximum overall cable distance (Maximum transmission distance): Ver. 1.10: 625 kbps | 900 m |
| Maximum overall cable distance (Maximum transmission distance): Ver. 1.10: 2.5 Mbps | 400 m |
| Maximum overall cable distance (Maximum transmission distance): Ver. 1.10: 5 Mbps | 160 m |
| Maximum overall cable distance (Maximum transmission distance): Ver. 1.10: 10 Mbps | 100 m |
| Station type | Local station (Ver. 1 local station) |
| Number of occupied stations: Local station | 1 or 4 stations |
| Maximum number of link points per system: CC-Link Ver.1 | Remote I/O (RX, RY) : 2048 points Remote register (RWw) : 256 points Remote register (RWr) : 256 points |
| Number of link points per station: CC-Link Ver.1 | Remote I/O (RX, RY) : 30 points Remote register (RWw) : 4 points Remote register (RWr) : 4 points |
| Communication method | Broadcast polling method |
| Synchronization method | Frame synchronization method |
| Encoding method | NRZI method |
| Network topology | Bus (RS-485) |
| Transmission format | HDLC compliant |
| Error control system | CRC (X 16 + X 12 + X 5 + 1) |
| Communication cable | Ver.1.10 compatible CC-Link dedicated cable CC-Link dedicated cable (Ver.1.00 compatible) CC-Link dedicated high-performance cable (Ver.1.00 compatible) |
| Number of installable boards | Maximum 4 boards (This indicates the total number of A80BDE-J61BT11 and A80BDE-J61BT13 boards.) |
| Installation slot | PCI slot |
| Internal current consumption (5 V DC) | 0.40 A |
| Weight | 0.16 kg |
Specifications
| Operating ambient temperature | 0...55 ˚C |
| Storage ambient temperature | -20...75 ˚C |
| Operating ambient humidity | 10...90 %RH, non-condensing |
| Storage ambient humidity | 10...90 %RH, non-condensing |
| Vibration resistance: Compliant with JIS B 3502 and IEC 61131-2: Under intermittent vibration | Frequency: 10...57 Hz, Amplitude: 0.075 mm Frequency: 57...150 Hz, Acceleration: 9.8 m/s 2 Sweep count: 10 times each in X, Y, Z directions |
| Vibration resistance: Compliant with JIS B 3502 and IEC 61131-2: Under continuous vibration | Frequency: 10...57 Hz, Amplitude: 0.035 mm Frequency: 57...150 Hz, Acceleration: 4.9 m/s 2 |
| Shock resistance | Compliant with JIS B 3502 and IEC 61131-2 (147 m/s 2 , 3 times each in 3 directions X, Y, Z) |
| Operating atmosphere | No corrosive gases |
| Operating altitude | 0...2000 m |
| Installation location | Inside a control panel |
| Overvoltage category | II or less |
| Pollution degree | 2 or less |
