Mitsubishi Electric A6BSW-P-S5

Mitsubishi MELSEC network modules Option

MPN
A6BSW-P-S5
Price and lead time confirmed within 1 business day

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original A6BSW-P-S5 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric A6BSW-P-S5?

The Mitsubishi Electric A6BSW-P-S5 is a option in the MELSEC network modules. Own station side (IN, OUT): SI optic cable, other station side (IN, OUT): GI optic cable, for optic data link fault station bypass, extending distance between stations, cable conversion. Mitsubishi Electric has discontinued it (2010/10 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSEC network modules
CategoryOption
TypeBypass switch
Sales status2010/10 Discontinued (Mitsubishi Electric)
OutlineOwn station side (IN, OUT): SI optic cable, other station side (IN, OUT): GI optic cable, for optic data link fault station bypass, extending distance between stations, cable conversion

Specifications

Bypass switching methodAutomatic switching by detecting the PC power OFF, or forced switching by the slide switch or external signal (12/24 VDC)
External input remote bypass: Rated input voltage12 V DC, 24 V DC
External input remote bypass: Rated input current4 mA, 10 mA
External input remote bypass: Operating voltage range10.2...26.4 V DC (ripple ratio: within 5 %)
External input remote bypass: ON voltage/ON current9 V or more/3 mA or more
External input remote bypass: OFF voltage/OFF current6 V or less/1.5 mA or less
External input remote bypass: Input resistanceApprox. 2.4 kΩ
Maximum number of switch units usable per loopnumber of slave stations in a loop + 2 units
External interfaceTerminal block (M3.5 screw)
External power supply: Rated power supply voltage100/120 V AC, 200/240 V AC, 50/60 Hz
External power supply: Operating voltage range85...264 V AC, 47...63 Hz
External power supply: Allowable momentary power failure time20 ms TYP. (100 V AC, 25 ˚C)
External power supply: Rated current consumption0.2 A (100 V AC, 25 ˚C)
Backup battery: built-in battery: TypeA6BSW-BAT Ni-Cd cell
Backup battery: built-in battery: Nominal voltage7.2 V
Backup battery: built-in battery: Backup time6 hours when 100 % charged (100 % charged after 40 hours of charging)
Backup battery: built-in battery: Charging methodCharged when the 100/200 VAC power is supplied.
Backup battery: External power supply: Rated voltage12 V DC
Backup battery: External power supply: Operating voltage range10.2...13.2 V DC
Backup battery: External power supply: Current consumption0.6 A
External dimensions: Height260 mm
External dimensions: Width240 mm
External dimensions: Depth91 mm
Weight4.0 kg (with built-in battery)

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

A6BSW-P-S5: frequently asked questions

Can I still buy the A6BSW-P-S5 now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the A6BSW-P-S5, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can A6BSW-P-S5 be shipped?

A6BSW-P-S5 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up A6BSW-P-S5 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for A6BSW-P-S5 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for A6BSW-P-S5, subject to availability and destination.
