A6BSW-R Mitsubishi MELSEC network modules Option

MPN: A6BSW-R · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original A6BSW-R (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC network modules – MELSECNET(II)/B
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the A6BSW-R now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the A6BSW-R, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can A6BSW-R be shipped?

A6BSW-R is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up A6BSW-R in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for A6BSW-R and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for A6BSW-R, subject to availability and destination.

The Mitsubishi Electric A6BSW-R is a option in the MELSEC network modules. Coaxial data link fault station bypass, number of slave stations can be increased, switch redundant operation of master station. Mitsubishi Electric has discontinued it (2011/04 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC network modules
Category	Option
Type	Coaxial loop
Subtype	Coaxial tap
Sales status	2011/04 Discontinued (Mitsubishi Electric)
Outline	Coaxial data link fault station bypass, number of slave stations can be increased, switch redundant operation of master station

Specifications

Bypass switching method	• Switching by turning ON/OFF the external power supply (when the SHORT terminals are shorted) • Switching by turning ON/OFF (short/open) the SHORT terminals (when the external power supply is always ON)
Maximum number of switch units usable per loop	128 units
Connectors: For the coaxial cable	BNC connector
Connectors: For the input power supply	Special connector
Connection cable: Coaxial cable	3C-2V/5V-2V
Connection cable: Input power supply cable	Finished outer diameter: Φ5 to 6 mm, core wire: 0.5 mm 2 or smaller
Indicator	State of STATION which is connected or not connected is indicated by a LED lamp.
External power supply: Rated power supply voltage	24 V DC
External power supply: Operating voltage range	20.4...26.4 V DC
External power supply: Rated current consumption	25 mA
External dimensions: Height	75 mm
External dimensions: Width	204 mm
External dimensions: Depth	40 mm
Weight	0.80 kg
