A6BR10-DC Mitsubishi MELSEC network modules Option

MPN: A6BR10-DC · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC network modules – MELSECNET/H
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can A6BR10-DC be shipped?

A6BR10-DC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up A6BR10-DC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for A6BR10-DC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for A6BR10-DC, subject to availability and destination.

The Mitsubishi Electric A6BR10-DC is a option in the MELSEC network modules. Repeater for MELSECNET/H and MELSECNET/10 coaxial bus system, input voltage: 24 V DC. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC network modules
Category	Option
Type	Coaxial bus
Subtype	Repeater for coaxial bus
Outline	Repeater for MELSECNET/H and MELSECNET/10 coaxial bus system, input voltage: 24 V DC

Specifications

Communication speed	10 Mbps
Maximum number of units to be installed per network	4
Extension distance per unit	300 m (3C-2V), 500 m (5C-2V, 5C-FB)
Overall cable distance	300 m × 5 = 1.5 km (3C-2V) 1.5 km × 5 = 2.5 km (5C-2V, 5C-FB)
Maximum number of connected stations	32 stations
Alarm output for abnormal continuous transmission	ERR1: On when the A6BR10 is abnomal (a power-off error). ERR2: On when the A6BR10 is nomal.
Alarm output for abnormal continuous transmission: Isolation method	Non-isolated
Alarm output for abnormal continuous transmission: Rated switching voltage/current	24 V DC, 2 A (resistive load), 240 V AC, 2 A (cosø=1)
Alarm output for abnormal continuous transmission: Minimum switching load	5 V DC, 1 mA
Alarm output for abnormal continuous transmission: Maximum switching voltage	264 V AC, 125 V DC
Alarm output for abnormal continuous transmission: Response time: OFF to ON	10 ms or less
Alarm output for abnormal continuous transmission: Response time: ON to OFF	12 ms or less
Alarm output for abnormal continuous transmission: Life: Mechanical	10 million times or more
Alarm output for abnormal continuous transmission: Life: Electrical	Rated switching voltage/current load: More than 100 thousand times 200VAC 1.5A, 240VAC 1A (COSø=0.7): 100 thousand times 200VAC 1A, 240VAC 0.5A (COSø=0.35): 100 thousand times 24VDC 1A, 100VDC 0.1A (L/R=7ms): 100 thousand times
Alarm output for abnormal continuous transmission: Surge suppressor	None
Module power supply: Voltage	24 V DC, -35/+30 % (15.6...31.2 V DC)
Module power supply: Maximum power	9 W
Module power supply: Current	0.6 A
Module power supply: Inrush current	17 A, within 1 ms
Module power supply: Efficiency	65 % or more
Module power supply: Allowable momentary power failure time	10 ms
External dimensions: Height	100 mm
External dimensions: Width	170 mm
External dimensions: Depth	80 mm
Weight	1.0 kg
