Danfoss FBF1000

HOSE-AER, FBF, -8, AC,GY

MPN
FBF1000
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FBF1000?

Danfoss HOSE-AER, FBF, -8, AC,GY, manufacturer part number FBF1000. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146025333
Abrasion resistancePremium
ApplicationAir conditioning
Bend radius min (inch)6.500
Bend radius min (mm)165.000
BrandAeroquip by Danfoss
Burst pressure (bar)138
Burst pressure (psi)2000
ColorStainless steel
CompliancesASTM D471
ConductivityNon-conductive
Construction1 Wire Braid
Cover materialStainless steel
Impulse cycle (cycles)150000
Inside diameter (inch)0.51
Inside diameter (mm)13.00
Lay line styleInk transfer
Outside diameter (inch)0.66
Outside diameter (mm)16.80
Package formBulk
Product height in0.510
Product height mm13.000
Product width in0.510
Product width mm13.000 mm
Qualified hose fittingsContact Danfoss for fittings
Reinforcement materialBrass plated steel wire
SeriesFBF Series
Size-8
Tube materialNylon 11
Tube wall thickness (inch)0.40
Tube wall thickness (mm)10.16
Working pressure max (bar)34
Working pressure max (psi)500
Working temperature max (C)121
Working temperature max (F)250.0
Working temperature min (C)-40
Working temperature min (F)-40.0

FBF1000: frequently asked questions

When can FBF1000 be shipped?

FBF1000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FBF1000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FBF1000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FBF1000, subject to availability and destination.
